Technical Specifications
Interfaces
1 10/100/1000Mbps LAN Port
1 10/100/1000Mbps WAN Port
1 USB 3.0 Port
Button
Reset Button
Antenna
13 high-performance Wi-Fi antennas
1 bluetooth antenna
1 zigbee antenna
External Power Supply
12V/3A
Others
Built-in speaker
Congestion sensing Wi-Fi radio
Wireless Standards
IEEE 802.11ac/n/a 5GHz Wi-Fi
IEEE 802.11b/g/n 2.4GHz Wi-Fi
Bluetooth Smart Ready
802.15.4 ready
Google Weave ready
Frequency
2.4GHz and 5GHz Band1/2/3/4 Wi-Fi
2.4GHz Bluetooth
2.4GHz Zigbee
Signal Rate
Wi-Fi
5GHz: Up to 1300Mbps
2.4GHz: Up to 600Mbps
Bluetooth 4.0 and HS
Reception Sensitivity
5GHz:
11a 6Mbps: -92dBm
11a 54Mbps: -75dBm
11ac HT20: -74dBm
11ac HT40: -71dBm
11ac HT80: -81dBm
2.4GHz:
11g 54M: -77dBm
11n HT20: -74dBm
11n HT40: -71dBm
Transmission Power
FCC: <30dBm
System Requirements
For initial setup, the Google On mobile app on a device with:
- Android 4.0 or higher
- iOS 7 or higher
Certifications
FCC, IC
Item Dimension (L"xW"xH")
6 x 6 x 10
Weight
3.61 lb
Warranty Information
2 Years
