Qnap TBS-453A-4G-US Storage TBS-453A-4G-US NASBook SSD 4Bay M.2 Dual HDMI 2x2GB DDR3L USB Retail

Compact, near-silent, and versatile, the 4-bay M.2 SSD NASbook TBS-453A is ideal for office meetings and multimedia applications. Featuring a quad-core Intel 1.6GHz processor, a built-in 4-port network switch, and using up to 4 M.2 SSDs for storage, the TBS-453A not only provides full-fledged NAS functions with RAID protection, but also can act as a switch and share network access with multiple users regardless of being powered on or off. Coupled with its dual HDMI output and 4K H.264 video display & transcoding abilities, the TBS-453A can easily be carried to meetings to present stored files and quality multimedia content. The TBS-453A also supports the open-source Linux platform that allows you to directly utilize feature-rich Linux apps, enjoying a private cloud combining storage and IoT applications.

• Built-in 4-port LAN switch, combined with advanced virtual switch functionality for maximized network flexibility
• Dual HDMI output with duplicated and extended desktop options
• Use the TBS-453A as a PC with exclusive QvPC Technology and 4K (H.264) support
• Supports Linux OS with direct output via HDMI
• Store, backup, and share files with snapshots and versioning
• Wide range 10V to 20V DC power input
• Expand the total raw storage capacity with a UX-800P/UX-500P expansion enclosure
• Build a karaoke system with the OceanKTV app

Processor
14nm Intel Celeron N3150 Quad Core 1.6GHz, burst up to 2.08GHz

Floating Point Unti
Yes

Hardware Encryption Acceleration
AES-NI

GPU
8th Generation Intel HD Graphics

System Memory
4GB (2x2GB)

Maximum Memory
8GB

Memory Slot
2, SODIMM DDR3L-1600

Flash
4GB

Drive Type
4 x M.2 2280/2260/2242 SATA 6Gb/s SSDs

Raw Capacity
Optional

Default Capacity (Factory Configuration)
Optional

Network
5 x Gigabit LAN ports (Port 1 and any of the four ports from 2-1 to 2-4 are available to the 2 built-in network cards, and the remaining three ports can work as switch ports.)

USB Ports
4 x USB 3.0 and 1 x USB 2.0 Ports
Support USB Printer, Pen Drive, and USB UPS, etc.

Video Output
2 x HDMI, up to 4K 2160P Ultra HD Support

Audio Input
2 x 3.5mm Microphone Jack (Dynamic Microphone Only)

Audio Output
1 x Built-in Speaker, 1 x Line Out Jack (for Amplifier or Headphone Amplifier)

Button
Power, USB One-Touch-Backup, Reset, Volume UP, Volume Down

IR Receiver
Support QNAP RM-IR002, RM-IR003 and MCE-Compatible Remote Control (DM)

Security
Kensington Security Slot

Power Consumption
System Sleep Mode: 0.98W
SSD Standby: 13.05W
In Operation: 15.2W

Sound Level
Sound Pressure (LpAm): 10.8 dB(A)

Working Temperature
0 to 40 C

Relative Humidity
5 to 95% RH Non-Condensing, Wet Bulb: 27 C

Power
DC 10V to 20V Wide Input Range

Fan
Compact Internal Fan

Package Contents
NASbook
65W 19V AC Adapter
Power Cord
Quick Installation Guide
2 x Ethernet Cable
Remote Control
SSD Installation Kit

Item Dimension (L"xW"xH")
1 x 10 x 7

Weight
1.60 lb

Warranty Information
2 Years
