Technical Specifications
Certifications
CE
FCC
VCCI
BSMI
RCM
Thunderbolt technology Case material
High quality aluminum for optimized heat dissipation Application
Up to four 2.5" or 3.5" SATA hard disk drives or solid state drives RAID mode
Non-RAID Interface/Ports
2 x Thunderbolt 3 (USB-C) ports
1 x DisplayPort 1.2 Data transfer
Thunderbolt 3 up to 40 Gbps
DisplayPort 1.2 (4K at 60 Hz) System requirements (PC)
Windows 7 (64-bit), Windows 10 (64-bit)
Computer with Thunderbolt 3 port System requirements (Mac)
macOS 10.12.4 and later
Computer with Thunderbolt 3 port System environment
Operating Temperature: 5oC to 35oC
Storage Temperature: -20oC to 60oC
Relative Humidity: 5% to 95% (non-condensing) Power supply
Internal 200W power supply (UL, CE, CB, TUV approved)
Input: AC 100-240V, 50Hz-60Hz
Output: DC +12V/16.6A Fan noise level
17.7 dB(A) Package contents
Thunder3 Quad X enclosure (drives not included)
Thunderbolt 3 USB-C cable
Setup guide Remarks
When connected to a Thunderbolt 2 computer via Thunderbolt 3 to Thunderbolt 2 adapter or when connected behind another Thunderbolt device in a daisy chain, power delivery will not be supported.
This product was designed for use with the fan on and passed engineering tests with the fan on. We have added a fan switch that can turn off the fan when a low-noise environment is needed. However, the device should only be used for short periods of time with the fan in the OFF position as prolonged use may cause the device to overheat and this may cause damage to the system, cause issues to data integrity, reduce system reliability and/or shorten the lifespan of the electrical components. For best results, we recommend that the device not be used continuously for more than 30 minutes with the fan in the OFF position.
This product has components or design elements that are patented or patent pending. Item Dimension (L inchxW inchxH inch)
10 x 6 x 9 Weight
15.00 lb Warranty Information
2 Years
