T1600G-28TS - Tplink TP-Link Network T1600G-28TS 24-Port Pure-Gigabit Smart Switch with 4xCombo SFP Retail

Special Order
Ships in 1-2 weeks
Condition: New

$177.02

AUTHORIZED
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

TP-LINK JetStream Gigabit Smart Switch T1600G-28TS is a cost-effective product solution for small- and medium-sized business that provides high-performance, powerful L2 and L2+ features like static routing, enterprise-level QoS and useful security strategies. Equipped with 24 Gigabit RJ-45 ports and four SFP slots, T1600G-28TS supports useful features. Static Routing helps route internal traffic for more efficient use of network resources. The Storm Control feature protects against Broadcast, Multicast and Unknown unicast Storm. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. Moreover, the easy-to-use web management interfaces, along with SNMP, RMON and Dual Image, mean faster setup and configuration with less downtime. For workgroup and departments requiring cost-sensitive L2/L2+ switch and Gigabit capability, TP-LINK JetStream Gigabit Smart Switch T1600G-28TS provides you the ideal access-edge solution.

Expert Overview

The TPLINK Network T1600G-28TS is a 24-port pure-gigabit smart switch designed for small to medium-sized businesses. This fanless unit provides a cost-effective solution for network infrastructure requiring L2 and L2+ capabilities. It features 24 10/100/1000Mbps RJ45 ports and four dedicated Gigabit SFP slots, offering flexible connectivity options. The switch supports static routing for efficient internal traffic management and includes enterprise-level Quality of Service (QoS) for traffic prioritization. Security features such as Storm Control, 802.1x authentication, and IP-MAC-Port Binding are integrated to protect network integrity. Management is facilitated through web-based GUIs, SNMP, and RMON, allowing for straightforward setup and configuration. The T1600G-28TS is suitable for workgroups and departments needing a reliable, Gigabit-capable access-edge switch.

Technical Specifications

Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, Interface
24 10/100/1000Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
4 Gigabit SFP Slots Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
1000BASE-X: MMF, SMF Fan Quantity
Fanless Power Supply
100 to 240V AC 50/60Hz Power Consumption
Maximum: 23.2W (220V/50Hz) Bandwidth/Backplane
56Gbps MAC Address Table
16k Packet Buffer Memory
41.7 Mpps Jumbo Frame
9216 Bytes Quality of Service
Support 802.1p CoS/DSCP priority
Support 8 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow-based Rate Limiting
Voice VLAN L2 and L2+ Features
Static Routing
IGMP Snooping V1/V2/V3
802.3ad LACP(Up to 14 aggregation groups, containing 8 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loop back detection
802.3x Flow Control VLAN
Supports IEEE 802.1Q up with 4k VLANs simultaneously (out of 4K VIDs)
Mac based VLAN
Protocol Based VLAN Access Control List
L2L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports Security
SSH v1/v2
SSL v3/TLS v1
Port Security
Broadcast/Multicast/Unknown-unicast Storm Control
802.1x and Radius Authentication
IP-MAC-Port Binding
ARP Inspection
Dos Defend IPv6
Dual IPv4/IPv6 stack
Multicast Listener Discovery (MLD) Snooping
IPv6 neighbor discovery (ND)
Path maximum transmission unit (MTU) discovery
Internet Control Message Protocol (ICMP) version 6
TCPv6/UDPv6 IPv6 Applications
DHCPv6 Client
Ping6
Tracert6
Telnet(v6)
IPv6 SNMP
IPv6 SSH
IPv6 SSL
Http/Https
IPv6 TFTP Management
Web-based GUI
SNMP v1/v2c/v3,compatible with public MIBs and
TP-LINK private MIBs
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Firmware Upgrade: Web
System Diagnose: VCT
SYSLOG Public MIBS
Dual Image Certification
CE, FCC, RoHS System Requirements
Microsoft Windows XP, Vista or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux

Product Details

  • Manufacturer:
  • Model Number:
  • ASIN:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • TPLINK
  • T1600G-28TS
  • B016M1QTS2
  • 845973091972
  • New
  • 6.5 lbs
  • 0 X 0 X 0
  • Jul 25, 2026
  • Feb 29, 2020
Product Identifiers: Brand: Tplink • Part #: T1600G-28TS • UPC: 845973091972 • ASIN: B016M1QTS2 • Category: Network Switches

Frequently Asked Questions

What type of network media is compatible with this switch?

For 10BASE-T, UTP category 3, 4, or 5 cable (up to 100m) is supported. For 100BASE-TX/1000Base-T, UTP category 5, 5e, or above cable (up to 100m) is required. 1000BASE-X connections utilize MMF or SMF.

What are the key L2 and L2+ features supported?

Key features include Static Routing, IGMP Snooping V1/V2/V3, 802.3ad LACP with up to 14 aggregation groups, Spanning Tree protocols (STP/RSTP/MSTP), and 802.3x Flow Control. It also supports IEEE 802.1Q VLANs with up to 4k VLANs simultaneously.

Does this switch support IPv6?

Yes, the switch features a Dual IPv4/IPv6 stack. It supports IPv6 applications such as DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, and IPv6 TFTP.

What is the power consumption of the T1600G-28TS?

The maximum power consumption for the T1600G-28TS is 23.2W when operating at 220V/50Hz. It is powered by a 100 to 240V AC 50/60Hz supply.
