Technical Specifications
Standards and Protocols:
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p Interface:
24 10/100Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
4 10/100/1000Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
2 Combo Gigabit SFP Slots Network Media:
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable(maximum 100m)
1000BASE-X: MMF, SMF PoE+ Ports(RJ45):
Standard: 802.3at/af compliant
PoE+ Ports: 24 Ports
Power Supply: 180W
Fan Quantity:
2
Power Consumption:
Maximum(PoE on): 222.15W (220V/50Hz)
Power Supply:
100240VAC, 50/60Hz PERFORMANCE
Bandwidth/Backplane:12.8Gbps
MAC Address Table:8k
Packet Forwarding Rate:9.5Mpps
Jumbo Frame:9216 Bytes Item Dimension (L"xW"xH"):
20.79 x 13.23 x 3.94
Weight:
38.36 lb
Warranty Information:
5 years
