SYS-F619P2-RTN(3YR) - Supermicro System SYS-F619P2-RTN 4U FatTwin Xeon S3647 C621 Maximum 1.5TB 2200 Watts RPS Brown Box

Motherboard
Super X11DPFR-SN Processor/Cache
CPU:
Dual Socket P (LGA 3647)
Intel Xeon Scalable Processors, Dual UPI up to 10.4GT/s
Support CPU TDP 70-165W with IVR
Cores: Up to 28 Cores with Intel HT Technology System Memory
Memory Capacity:
12 DIMM slots
Up to 1.5TB ECC 3DS LRDIMM, 1.5TB ECC RDIMM, DDR4 up to 2666MHz
Memory Type:
2666/2400/2133MHz ECC DDR4 SDRAM On-Board Devices
Chipset: Intel C621 chipset
SATA: SATA3 (6Gbps) RAID 0, 1, 5, 10
Network Controllers: Flexible networking via SIOM
IPMI:
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics: ASPEED AST2500 BMC Input / Output (per node)
SATA: 14 SATA3 (6Gbps) ports
NVMe: 4 NVMe U.2 option
LAN:
SIOM flexible Network card
1 RJ45 Dedicated IPMI LAN port
USB : 2 USB 3.0 ports (rear)
VGA: 1 VGA port System BIOS
BIOS Type: 128Mb SPI Flash EEPROM with AMI BIOS Management
Software:
Intel Node Manager
IPMI 2.0
KVM with dedicated LAN
SuperDoctor 5
Watch Dog
Power Configurations: ACPI Power Management PC Health Monitoring
CPU:
Monitors for CPU Cores, Chipset Voltages, Memory.
4+1 Phase-switching voltage regulator
FAN:
Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature:
Chassis
Form Factor: 4U Rackmount
Model: CSE-F418BC2-R2K20BP
Available Colors: Black Front Panel
Buttons:
Power On/Off button
UID button
LEDs:
Power status LED
Hard drive activity LED
Network activity LEDs
Information LED (UID, Fan failure, Overheat) Expansion Slots (per node)
PCI-Express:
1 PCI-E 3.0 x16 (Low-profile)
1 PCI-E 3.0 x16 (SIOM) Drive Bays (per node)
Hot-swap: 6 Hot-swap 2.5" SATA3 or 2 Hot-swap 2.5" SATA3 + 4 NVMe U.2
M.2: M.2 Support Backplane
1 SAS/SATA backplane System Cooling (per node)
Fans: 3x 4cm 20k RPM middle fans Power Supply
2200W Redundant Power Supplies with PMBus
Total Output Power and Input:
1200W with Input 100-127Vac
1800W with Input 200-220Vac
1980W with Input 220-230Vac
2090W with Input 230-240Vac
2200W with Input 220-240Vac (for UL/cUL use only)
2090W with Input 230-240Vdc (for CCC only)
AC Input Frequency: 50-60Hz
Dimension (W x H x L): 76 x 40 x 336 mm
+12V:
Max: 100A / Min: 0A (100-127Vac)
Max: 150A / Min: 0A (200-220Vac)
Max: 165A / Min: 0A (220-230Vac)
Max: 174.17A / Min: 0A (230-240Vac)
Max: 183.3A / Min: 0A (220-240Vac)
5VSB: Max: 1A / Min: 0A
Output Type: Backplanes (gold finger)
Certification:
UL/cUL/CB/BSMI/CE/CCC
Titanium Level Operating Environment
RoHS: RoHS Compliant
Environmental Spec.:
Operating Temperature: 10^oC - 35^oC (50^oF - 95^oF)
Non-operating Temperature: -40^oC to 60^oC (-40^oF to 140^oF)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing) Item Dimension (L"xW"xH")
43 x 29 x 15

Weight
200 lbs

Warranty Information
3 Years
