Technical Specifications
Motherboard
Super A2SAP-H Processor/Cache
CPU
Intel Atom processor E3940
Single socket FCBGA 1296
9.5W, 4C System Memory
Memory Capacity
Up to 8GB Unbuffered non-ECC SO-DIMM, DDR3L-1866MHz, in 1 DIMM socket
Memory Type
DDR3L up to 1866MHz
DIMM Sizes
8GB, 4GB
Memory Voltage
1.35 V On-Board Devices
Chipset
System on Chip
Network Controllers
Dual LAN with Intel Ethernet Controller I210-IT
Audio
ALC 888S HD Audio
Graphics
Intel HD Graphics
HDMI (max. resolution up to 3840 x 2160 at 30Hz) Input / Output
LAN
2 RJ45 Gigabit Ethernet LAN ports
Wifi
Dual Band Wireless and Bluetooth 4.2
USB
2 USB 3.0 ports (rear)
2 USB 2.0 ports
Video
2 HDMI ports
COM
2 COM (RS-232/422/485)
TPM
1 TPM 2.0 onboard Chassis
Form Factor
Proprietary
Model
CSE-E50
Available Colors
Black Front Panel
Buttons
Power On/Off button
LEDs
Power LED (Hard drive activity LED) Expansion Slots
PCI-Express
1 Full size Mini-PCIe
1 Half size Mini-PCIe
M.2
1 M.2 B-Key 2242/3042 for storage Drive Bays / Storage
Internal
1 SATA 3.0 for 7mm 2.5" SATA SSD OR
1 M.2 B-Key 2242/3042 for SATA SSD System Cooling
Fans
Fanless design Power Supply
40W lockable 12V DC power adapter System BIOS
BIOS Type
AMI UEFI Management
Software
SuperDoctor 5
Watch Dog
Power Configurations
+12V DC Power Input
ACPI Power Management
Control of power-on for recovery from AC power loss
Force Power On by Jumper Operating Environment / Compliance
RoHS
RoHS Compliant
Environmental Spec.
Operating Temperature:
0oC to 50oC (32oF to 122oF)
Non-operating Temperature:
-40oC to 70oC (-40oF to 158oF)
Operating Relative Humidity:
8% to 90% (non-condensing)
Non-operating Relative Humidity:
5% to 95% (non-condensing)
Regulatory
Regulatory applied to US and EU. Please consult local representatives. Item Dimension (L"xW"xH")
5 x 2 x 5
Weight
3.52 lbs
Warranty Information
1 year
