Supermicro SYS-E100-9S-L System SYS-E100-9S-L Core i3-7100U 32GB FCBGA1356 mPCIE DP/HDMI Black Brown Box

Motherboard
Super X11SSN-L Processor/Cache
CPU:
7th Generation Intel Core i3-7100U Processor
Single Socket FCBGA 1356
System-on-Chip
CPU TDP support 15W System Memory
Memory Capacity: Up to 2 Unbuffered non-ECC SO-DIMM, DDR4-2133MHz, in 2 DIMM slots
Memory Type: DDR4 up to 2133MHz
DIMM Sizes: 16GB, 8GB, 4GB
Memory Voltage: 1.2V On-Board Devices
Chipset: System on Chip
Network Controllers:
Single LAN with Intel I210IT
Single LAN with Intel PHY I219LM
Video: Intel HD Graphics 620 Input / Output
USB:
1 USB 3.1 (Type C)
2 USB 3.0 (rear via header)
4 USB 2.0 (rear via headers)
Video Output:
1 DP (Display Port) port
1 HDMI port
COM Port:
4 COM ports (4 headers)
2 RS232, 2 RS232/422/485, RS-485 supports auto flow control
Audio: 1 HD Audio header (Mic-in/Line-Out) (option)
Others: 1 DIO via DB9 Chassis
Form Factor: 3.5" SBC
Model: CSE-E101-01
Available Colors: Black Front Panel
Buttons: Power On/Off button
LEDs: Power LED and Hard drive activity LED Expansion Slots
PCI-Express: 1 Full size Mini-PCIe (1 USB 2.0, 1 PCIe Gen2, 1 SATA Gen3)
M.2:
Interface: SATA and PCIe 3.0 x1 and USB 2.0
Form Factor: B-Key 2242, 2280 Drive Bays
Internal: 1 M.2 2280 B-Key for SATA or PCIe SSD (2242 can be supported with bracket) System Cooling
Fans: Fan-less design Power Supply
Lockable 12V DC 60W power adapter System BIOS
BIOS Type: AMI UEFI Management
Software:
SuperDoctor 5
Watch Dog
Power Configurations:
+12V DC Power Input
ACPI Power Management
Control of power-on for recovery from AC power loss
Force Power On by Jumper
CPU thermal trip support for processor protection Operating Environment / Compliance
RoHS: RoHS Compliant
Environmental Spec.:
Operating Temperature: 0^oC - 50^oC (32^oF - 122^oF)
Non-operating Temperature: -40^oC to 70^oC (-40^oF to 158^oF)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing) Item Dimension (L"xW"xH")
NA

Weight
3 lbs

Warranty Information
1 year
