Supermicro SYS-6028R-T System SYS-6028R-T 2U Xeon E5-2600v3 LGA2011 C612 DDR4 SATA PCI-Express 650W Retail

Motherboard
Super X10DRi Processor/Cache
CPU
Intel Xeon processor E5-2600 v4^note / v3 family (up to 145W TDP)
Dual Socket R3 (LGA 2011) Cores / Cache
Up to 22 Cores^note / Up to 55MB^note Cache System Bus
QPI up to 9.6 GT/s Note
BIOS version 2.0 or above is required System Memory
Memory Capacity
16x 288-pin DDR4 DIMM slots
Up to 2TB^note ECC 3DS LRDIMM, 512GB ECC RDIMM Memory Type
2400^note /2133/1866/1600MHz ECC DDR4 SDRAM 72-bit DIMM Sizes
RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
3DS LRDIMM: 128GB Memory Voltage
1.2 V
Error Detection
Corrects single-bit errors On-Board Devices
Chipset
Intel C612 chipset SATA
SATA 3.0 (6Gbps) with RAID 0, 1, 5, 10 IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
ASPEED AST2400 BMC Network Controllers
Intel i350 Dual Port Gigabit Ethernet
Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
1x Realtek RTL8201N PHY (dedicated IPMI) Graphics
ASPEED AST2400 BMC Input / Output
Serial ATA
6x SATA3 (6Gbps) ports
2x SATA3 (6Gbps) ports onboard
2x SATA3 powered ports that support SATA DOM LAN
2x RJ45 Gigabit Ethernet LAN ports
1x RJ45 Dedicated IPMI LAN port USB
Rear USB: 2x USB 3.0 + 2x USB 2.0
USB Header: 2x 3.0, 4x 2.0, 1x Type A VGA
1x VGA port
Serial Port / Header
1x COM Port Management
Software
SuperDoctor 5
Watch Dog
NMI, SPM, SUM
IPMI 2.0
Intel Node Manager
