Specifications
- Motherboard: Super X9DRW-7TPF+
- Processor: Dual LGA2011 Support Intel Xeon E5-2600 Processors
- Chipset: Intel C602J
- Memory: Supports up to 768GB ECC/REG Memory or up to 128GB ECC/Unbuffered Memory
- Slots (via Riser Card):
- Left: 1x PCI-Express 3.0 x16 Slot, 2x PCI-Express 3.0 x8 Slots (Full-height)
- Right: 2x PCI-Express 3.0 x8 Slots (Low-profile)
- SATA: 2x SATA2 Ports, Support RAID 0, 1; SATA2 Supports RAID 0, 1, 5, 10
- SAS: 8x SAS2 Ports, Support RAID 0, 1, 5, 6, 10, 50, 60
- Video: Matrox G200eW Graphics
- LAN: Intel 82599 Dual Port 10-Gigabit SFP+ and Intel i350 Dual Port Gigabit Ethernet Controllers; 1x Realtek RTL8201N PHY (dedicated IPMI)
- Drive Bays: 10x 3.5" Hot-swap SAS/SATA HDD Trays
- Backplane: 1x SAS2/SATA Backplane
- Ports: 5x USB 2.0 Ports, 1x VGA Port, 2x Serial Ports, 2x SFP+ LAN Ports, 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
- Form Factor: 2U Rackmount
- Power Supply: 920W 80 PLUS Platinum Certified High-efficiency AC-DC Redundant Power Supplies
- System Cooling: 4x 8cm Heavy Duty PWM Fans
- Front Panel:
- Buttons: Power On/Off, System Reset
- LEDs: Power Status, Hard Drive Activity, Network Activity, System Overheat, Power Fail
- Color: Black
- Dimensions (WxDxH): 17.20 x 27.75 x 3.50 inch / 437.0 x 705.0 x 89.0 mm
- Gross Weight: 52.0 lbs / 23.6 kg
- RoHS Compliant
Manufacturer Part Number:SYS-6027R-72RFTP+UPC:672042132782
