SYS-5039MP-H8TNR - Supermicro 3U MICROCLOUD SYSTEM X11SPD-F

Motherboard
Super X11SPD-F

Processor/Cache (per Node)
CPU
Single Socket P (LGA 3647)
2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
Support CPU TDP 165W
Cores
Up to 28 Cores
Note
Low TCase CPUs may require additional configuration. Please contact Supermicro Sales contact for additional information.
Note
BIOS version 3.2 or above is required to support 2nd Gen Intel Xeon Scalable processors (codenamed Cascade Lake-R)

System Memory (per node)
Memory Capacity
4 DIMM slots
Up to 1TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
Supports Intel Optane^TM DCPMM
Memory Type
2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
Note
2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
Cascade Lake only. Contact your Supermicro sales rep for more info.

Network Devices (per node)
Micro-LP NIC
Intel i350 GbE LAN controller
Dual RJ-45 connectors
MicroLP Adapter Matrix (Networking options)

On-Board Devices (per node)
Chipset
Intel C621 chipset
SATA
SATA3 (6Gbps) via C621 controller
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM over LAN support
ASPEED AST2500 BMC
Graphics
ASPEED AST2500 Graphics (BMC with Graphic controller)

Input / Output (per node)
SATA
2 SATA3 (6Gbps) ports
LAN
2 RJ45 Gigabit Ethernet LAN ports
KVM
1 VGA, 1 COM and 2 USB 2.0 (with KVM dongle)

System BIOS
BIOS Type
128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features
DMI 2.3
ACPI 1.0 / 2.0
USB Keyboard support
SMBIOS 2.3

Management
Software
Intel Node Manager
IPMI 2.0
KVM with dedicated LAN
SSM, SPM, SUM
SuperDoctor 5
Watchdog

Rear Window (each node)
Switch
Power / UID

Chassis
Form Factor
3U
Model
CSE-938NH-R2K20BP

Color
Black

Front Panel
Buttons
Power On/Off button
LEDs
Power LED
Node status LED

Expansion Slots (per node)
PCI-Express
1 PCI-E 3.0 x16 (Low-profile) slot
1 Micro-LP PCI-E 3.0 x8 slot
M.2
M.2 Interface: 2 SATA/PCI-E 3.0 x4
M.2 Form Factor: 2280
M.2 Key: M-Key

Drive Bays (per node)
Internal
2x 3.5" SATA3 (6Gbps) HDDs per node (or 2x 2.5" Hybrid SATA3/NVMe with optional kits), up to 16 HDDs total
Enterprise SATA HDD only recommended

System Cooling
Fans
4 Hot-swap 8cm cooling fans fan speed control

Power Supply
2200W Redundant Power Supplies with PMBus
Total Output Power and Input
1200W with Input 100-127Vac
1800W with Input 200-220Vac
1980W with Input 220-230Vac
2090W with Input 230-240Vac
2200W with Input 220-240Vac (for UL/cUL use only)
2090W with Input 230-240Vdc (for CCC only)
AC Input Frequency
50-60Hz
+12V
Max: 100A / Min: 0A (100-127Vac)
Max: 150A / Min: 0A (200-220Vac)
Max: 165A / Min: 0A (220-230Vac)
Max: 174.17A / Min: 0A (230-240Vac)
Max: 183.3A / Min: 0A (220-240Vac)
5VSB
Max: 1A / Min: 0A
Output Type
Backplanes (gold finger)
Certification
Titanium Level

PC Health Monitoring
CPU
Monitors for CPU Cores, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory, Chipset Voltages.
5 Phase-switching voltage regulator with auto-sense from 0.8375V-1.60V
FAN
Cooling zone
Temperature
Monitoring for CPU and chassis environment

Operating Environment / Compliance
RoHS
RoHS Compliant
Environmental Spec.
Operating Temperature:
10^oC to 35^oC (50^oF to 95^oF)
Non-operating Temperature:
-40^oC to 70^oC (-40^oF to 158^oF)
Operating Relative Humidity:
8% to 90% (non-condensing)
Non-operating Relative Humidity:
5% to 95% (non-condensing)

Item Dimension (L inchxW inchxH inch)
34 x 27 x 12

Weight
88.00 lb

Warranty Information
1 Year
