Supermicro SYS-5039AD-I(3YR) SuperServer 5039AD-I Server Barebone System - Mid-tower - Socket R4 LGA-2066 - 1 x Processo

Motherboard
Super C9X299-PGF Processor/Cache
CPU:
Single socket R4 (LGA 2066) supported, CPU TDP support up to 165W
Intel Core^TM i9/i7/i5 X-Series, and Intel Core^TM i9 Extreme X-Series Processors
System Memory
Memory Capacity:
8x 288-pin DDR4 DIMM slots
Supports up to 128GB DDR4 Non-ECC Un-Buffered memory (UDIMM)
Memory Type: 2666/2400/2133/1866/1600MHz Non-ECC DDR4 288-pin UDIMM
DIMM Sizes: 16GB, 8GB, 4GB
Memory Voltage: 1.2V
On-Board Devices
Chipset: Intel X299 Chipset
SATA: SATA3 via PCH w/ RAID 0, 1, 5, 10
IPMI: ASPEED AST2500
Network Controllers:
Single LAN with Intel Ethernet Controller I210-AT, shared IPMI port
Single LAN with Aquantia 5G LAN chip AQC108
Audio: ALC 1220 7.1 HD Audio
Input / Output
SATA: 6 SATA3 (6Gbps) ports
LAN: 2 RJ45 Gigabit Ethernet LAN ports
USB:
4 USB 3.0 ports (2 rear + 2 front)
4 USB 3.1 ports (rear, 3 Type A + 1 Type C)
Display: 1 VGA port
Serial Port / Header: 1 COM Port (1 header)
Expansion Slots
PCI-Express:
4 PCI-E 3.0 x16 slots
1 PCI-E 3.0 x1 slot
4 PCI-E 3.0 x16 slots (8/NA/16/16 or 8/8/8/16 or NA/4/8/16 (Skylake-X 28 Lanes) or NA/4/4/8 (Kabylake-X), 1 PCI-E 3.0 x1 slot
M.2:
M.2 Interface: 2 PCI-E 3.0 x4
Form Factor: 22110/2280
Key: M-Key (RAID 0, 1 support)
M-Key for SSD and Optane
U.2: U.2 Interface: PCI-E 3.0 x4 (for Skylake-X only)
System BIOS
BIOS Type: UEFI 128Mb
BIOS Features:
ACPI 3.0 or later
SMBIOS 2.7 or later
BIOS rescue hot-key
SPI dual/quad speed support
Overclock support
Chassis
Form Factor :Mid-Tower
Model :CSE-GS5A-753R Front Panel
Buttons :
Power On/Off Button
Reset Button
LEDs :
Power LED
Hard drive activity LED
Ports :
2 USB 3.0 ports
1 Earphone, 1 Microphone port
Drive Bays
Fixed :
6 fixed 3.5" drive bays
4 fixed 2.5" drive bays
Peripheral :2 standard 5.25" drive bays
System Cooling
Fans :
2x 12cm front cooling fans
1x 12cm rear exhaust fan
Power Supply
750W Multi-output Power Supply for Desktop, semi-modular cable output
AC Input :100-240Vac, 50-60Hz
+5V :Max: 20A Min: 0A
+12V :Max: 62A Min: 0.1A (100Vac-240Vac)
+3.3V :Max: 20A Min: 0A
+5V SB :Max: 2.5A Min: 0A
-12V :Max: 0.3A
Certification
Gold Certified
PC Health Monitoring
Voltage :+12V, +3.3V, +5V, 1.05 (PCH), 1.2V (VDIMM), 3.3V standby, Chassis intrusion header, Monitors CPU voltages, VBAT
FAN :5x 4-pin fan headers (up to 5 fans), Fan speed control, Overheat LED indication, PWM fan speed control, Thermal control tachometer fan connectors
Other Features :ACPI power management, ATX Power connector, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Intel Smart Response Technology, Voltage and Frequency Overclocking, WOL
Operating Environment / Compliance
RoHS: RoHS Compliant
Environmental Spec. :
Operating Temperature: 10^oC to 35^oC (50^oF to 95^oF)
Non-operating Temperature: -40^oC to 70^oC (-40^oF to 158^oF)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
Item Dimension (L inchxW inchxH inch)
24 x 15 x 25

Weight
55.00lb

Warranty Information
3 Years
