Technical Specifications
Motherboard
Super X11SPM-F
Processor/Cache
CPU
Single Socket P (LGA 3647)
2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
Support CPU TDP 70-165W Cores
Up to 28 Cores Note
BIOS version 3.2 or above is required to support 2nd Gen Intel Xeon Scalable processors (codenamed Cascade Lake-R).
Extended thermal solutions may be required to support CPUs higher than 165W TDP, please contact Supermicro Technical Support for additional information. System Memory
Memory Capacity
6 DIMM slots
Up to 1.5TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM Memory Type
2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM Note
2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro On-Board Devices
Chipset
Intel C621 chipset
SATA
SATA3 (6Gbps) via C621 controller
RAID 0, 1, 5, 10 support Network Controllers
Dual Gigabit Ethernet LAN with Marvell 88E1512
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Video
ASPEED AST2500 BMC
Input / Output
SATA
12 SATA3 (6Gbps) ports LAN
2 RJ45 1GbE LAN ports
1 RJ45 Dedicated IPMI LAN port USB
5 USB 3.0 ports (2 rear + 2 headers + 1 Type A)
6 USB 2.0 ports (2 rear + 4 headers) Video
1 VGA port
Serial Port / Header
2 COM ports (1 rear, 1 header) SuperDOM
2 SuperDOM (Disk on Module) ports with built-in power System BIOS
BIOS Type
AMI UEFI Management
Software
Intel Node Manager
IPMI 2.0
KVM with dedicated LAN
NMI
SPM, SUM
SuperDoctor 5
Watch Dog Power Configurations
ACPI Power Management
PC Health Monitoring
CPU
Monitors for CPU Cores, Chipset Voltages, Memory.
4+1 Phase-switching voltage regulator FAN
Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors Temperature
Monitoring for CPU and chassis environment
Thermal Control for fan connectors
