SYS-5018A-TN4 - Supermicro SuperServer 5018A-TN4

Motherboard
Super A1SAi-2750F

Processor/Cache
CPU
Intel Atom Processor C2750
CPU TDP 20W (8-Core)
FCBGA 1283
System-on-Chip System Memory
Memory Capacity
4x 204-pin DDR3 SO-DIMM sockets
Supports up to 32GB DDR3 ECC memory
Memory Type
1600/1333MHz ECC DDR3 SDRAM 72-bit, 204-pin gold-plated DIMMs
DIMM Sizes
8GB, 4GB, 2GB
Memory Voltage
1.5 V, 1.35 V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory) On-Board Devices
SATA
C2000 SoC SATA3 (6Gbps), SATA2 (3Gbps)
Network Controllers
C2000 Soc I354 Quad GbE Controllers (MACs)
Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Graphics
BMC integrated Aspeed AST2400
USB 3.0
Renesas uPD720201 Input / Output
Serial ATA
2x SATA3 (6Gbps) ports
4x SATA2 (3Gbps) ports

LAN
4x RJ45 Gigabit Ethernet LAN ports

USB
4x USB 3.0 ports (2 rear, 1 Type A, 1 via header)
2x USB 2.0 ports (2 rear) Serial Port
2x Fast UART 16550 Serial Port (1 rear, 1 via header)
DOM
1x SATA DOM (Disk on Module) power connector
VGA
1x VGA Port
Others
TPM 1.2 header
4-pin 12V DC power input or 24-pin ATX power input Form Factor
1U Rackmount

Available Colors
Black

Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED
Information LED (temp., status) Expansion Slots
PCI-E
1x PCI-E 2.0 x8 slot via riser

Drive Bays
HDD
2x 3.5" or 4x 2.5" internal SATA2 hard
drive bays (optional) Power Supply
200W Low Noise AC-DC power supply with PFC
AC Voltage
100 - 240V, 50-60Hz, 2.6 Amp Max
+5V
8.0 Amp (max.)
+5V standby
2.0 Amp (max.)
+12V
16 Amp (max.)
-12V
0.5 Amp (max.)
+3.3V
8.0 Amp (max.)
Certification
Gold Certified System BIOS
BIOS Type
64Mb SPI Flash EEPROM with AMI UEFI BIOS
BIOS Features
Plug and Play (PnP)
DMI 2.3
ACPI 5.0
USB Keyboard support
SMBIOS 2.7.1
UEFI

RoHS
RoHS Compliant Item Dimension (L"xW"xH"):
17.2 x 9.8 x 1.7

Weight:
12 lb

Warranty Information:
1 Year
