Technical Specifications
Output
Output Power Capacity :12.8 kW / 16 kVA
Max Configurable Power :12.8 kW / 16 kVA
Nominal Output Voltage :120V, 208V
Output Voltage Note :Configurable for 120/208 or 120/240 output voltage
Output Voltage Distortion :Less than 5% at full load
Output Frequency (sync to mains) :47 - 63 Hz
Other Output Voltages :240 Crest Factor :up to 5 : 1
Topology :Double Conversion Online
Waveform Type :Sine wave
Output Connections:
(1) Hard Wire 4-wire (2PH + N +G)
(4) NEMA L14-30R
(8) NEMA L5-20R
Bypass :Internal Bypass (Automatic and Manual), Optional External Bypass Input
Nominal Input Voltage: 208V
Input Frequency :45 - 65 Hz (auto sensing)
Input Connections :Hard Wire 4-wire (2PH+N+G)
Input voltage range for main operations :96 - 138 (Line to Neutral)V
Other Input Voltages :240V
Input Total Harmonic Distortion :Less than 7% for full load Batteries and Runtime
Battery Type :Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules :4
Typical recharge time :3 hour(s)
Replacement Battery :SYBT5
Extended Run Options :APC Symmetra LX 16kVA Scalable to 16kVA N+1 Rack-mount, 208/240V Communications and Management
Interface Port(s) :DB-9 RS-232, RJ-45 10/100 Base-T, Smart-Slot
Available SmartSlot Interface Quantity :1
Pre-Installed SmartSlot Cards :AP9631
Control panel :Multi-function LCD status and control console
Audible Alarm :Audible and visible alarms prioritized by severity
Emergency Power Off (EPO) :Yes Color
Black, Silver
Conformance
Regulatory Approvals :CSA, FCC Part 15 Class A, OSHPD, UL 1778 Item Dimension (L"xW"xH"):
39.25 x 23.60 x 41.50
Weight:
749 lb
Warranty Information:
2 years repair or replace
