Technical Specifications
Output
Output Power Capacity :8000 Watts / 10 kVA
Max Configurable Power :8000 Watts / 10 kVA
Nominal Output Voltage :120V, 208V, 208V 3PH Output Voltage Note :Configurable for 208 and 220V - 3 Phase
Efficiency at Full Load :93.0%
Output Voltage Distortion :Less than 5% at full load Output Frequency (sync to mains) :57 - 63 Hz for 60 Hz nominal
Other Output Voltages :220
Crest Factor :Unlimited
Topology :Double Conversion Online
Waveform Type :Sine wave Output Connections :
(1) Hard Wire 4-wire (3PH + G)
(1) Hard Wire 5-wire (3PH + N + G)
(1) Screw Terminals
Bypass :Built-in Maintenance Bypass, Built-in Static Bypass Input
Nominal Input Voltage :208V 3PH
Input Frequency :40 - 70 Hz
Input Connections :Hard Wire 5-wire (3PH + N + G) Input voltage range for main operations :165 - 240V
Other Input Voltages :220
Maximum Input Current :27A
Input Breaker Capacity :34.0 A Batteries and Runtime
Battery Type :Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time :5 hour(s)
RBC Quantity :2 Nominal Battery Voltage :+/-192 V (split battery referenced to neutral)
End of Discharge Battery Voltage :+/-154 V
Extended Run Options :APC Smart-UPS VT 10kVA 208V w/2 Batt Mod Exp to 4, Start-Up 5X8, Int Maint Bypass, Parallel Capable Communications and Management
Interface Port(s) :DB-9 RS-232, SmartSlot
Control panel :Multi-function LCD status and control console
Audible Alarm :Audible and visible alarms : configurable delays
Emergency Power Off (EPO) :Yes Item Dimension (L"xW"xH"):
64.70 x 25.60 x 41.80
Weight:
1183 lb
Warranty Information:
NA
