Technical Specifications
Output
Output Power Capacity :2100 Watts / 3000 VA
Max Configurable Power :2100 Watts / 3000 VA
Nominal Output Voltage :120V
Output Voltage Distortion :Less than 3%
Output Frequency (sync to mains) :50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Crest Factor :3 : 1
Topology :Double Conversion Online
Waveform Type :Sine wave
Output Connections:
(6) NEMA 5-15R
(2) NEMA 5-20R
Bypass :Internal Bypass (Automatic and Manual) Input
Nominal Input Voltage :120V
Input Frequency :50/60 Hz +/- 5 Hz (auto sensing)
Input Connections :NEMA L5-30P
Cord Length :2.44 meters
Input voltage range for main operations :90 - 150V Batteries and Runtime
Battery Type :Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules :2
Typical recharge time :2.50 hour(s)
Replacement Battery :RBC44
RBC Quantity :1
Extended Run Options :APC SMART-UPS RT 3000VA 120V Communications and Management
Interface Port(s) :DB-9 RS-232, Smart-Slot
Available SmartSlot Interface Quantity :1
Control panel :LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : Overload and Bypass Indicators
Audible Alarm :Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO) :Yes Surge Protection and Filtering
Surge energy rating :480 Joules
Filtering :Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 Conformance
Regulatory Approvals :CSA, FCC Part 15 Class A, UL 1778
Standard Warranty :2 years repair or replace Item Dimension (L"xW"xH"):
13.68 x 23.73 x 38.60
Weight:
140 lb
Warranty Information:
2 Years Repair and Replace
