Technical Specifications
Output
Output Power Capacity :1600 Watts / 2200 VA
Max Configurable Power :1600 Watts / 2200 VA
Nominal Output Voltage :120V
Output Voltage Distortion :Less than 5% at full load
Output Frequency (sync to mains) :47 - 53 Hz for 50 Hz nominal,57 - 63 Hz for 60 Hz nominal
Waveform Type :Sine wave
Output Connections :(8) NEMA 5-15R Input
Nominal Input Voltage :120V,230V
Input Frequency :50/60 Hz +/- 3 Hz (auto sensing)
Input Connections :
NEMA 5-20P
Schuko CEE 7 / EU1-16P
British BS1363A
Italian CEI 23-16
Cord Length :1.83 meters Batteries and Runtime
Battery Type :Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time :3 hour(s)
Replacement Battery :RBC12
RBC Quantity :1 Communications and Management
Interface Port(s) :DB-9 RS-232,SmartSlot
Available SmartSlot Interface Quantity :1
Control panel :
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators
Audible Alarm :Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO) :Optional Surge Protection and Filtering
Surge energy rating :480 Joules
Filtering :Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Regulatory Approvals
CSA,FCC Part 15 Class A,UL 1778 Item Dimension (L"xW"xH"):
10 x 24.50 x 37.50
Weight:
123 lb
Warranty Information:
NA
