Special Order
Ships in 1-2 weeks
Condition: New
| Audio Interface | PCI Express |
|---|---|
| Output Signal-to-Noise Ratio (A-Weighted) (Front-out) | 124 dB |
| Output Signal-to-Noise Ratio (A-Weighted) (Headphone-out) | 124 dB |
| Input Signal-to-Noise Ratio (A-Weighted) | 117 dB |
| Output THD+N at 1kHz (Front-out) | 0.0009 percent (-107 dB) |
| Output THD +N at 1kHz (Headphone-out) | 0.0009 percent (-107 dB) |
| Input THD +N at 1kHz | 0.000316 percent (-110 dB) |
| Frequency Response (-3dB, 24bit/96KHz input) | 10 Hz to 48 KHz |
| Output/Input Full-Scale Voltage | |
| Line output (RCA, 3.5) | 2 Vrms (5.65 Vp-p) |
| Chipset | |
| Audio Processor | C-Media USB2.0 6632AX High-Definition Sound Processor (Max. 384KHz / 24bit) |
| Digital-to-analog Converter(DAC) | ESS SABRE9016 Premier 8 Channel Audio DAC |
| Analog Playback Sample Rate and Resolution | 44.1K/48K/88.2K/96K/176.4K/192KHz at 16bit/24bit |
| Analog Recording Sample Rate and Resolution | 44.1K/48K/88.2K/96K/176.4K/192KHz at 16bit/24bit |
| S/PDIF Digital Output | 44.1K/48K/96K/192KHz at 16bit/24bit |
| ASIO 2.0 Driver Support | 44.1K/48K/96K/192KHz at 16bit/24bit with very low latency |
| Analog Output | 5 x 3.5 mm jack (1/8 inch) (Headphone out /Front out/Side out/Center-Subwoofer out/Rear out) |
| Analog Input | 1 x 3.5 mm jack (1/8 inch) (Line-in/ Mic-in combo) |
| Digital | 1 x S/PDIF out ((combo with side out)) |
| Special Features | Sonic Studio |
| Operating System | Windows 10 , 32bit/64bit |
