Technical Specifications
Capacity
10TB Generation
V6 Special Features
Multi-Step Forged Helium Sealed-Drive Design
Superior Wide-Weld Hermetically Sealed-Drive Enclosure
Digital Sensors for Humidity, Helium Pressure and Temperature
SuperParity
Low Halogen
PowerChoice idle Power Technology
PowerChoice PowerPerformance Technology
RAID Rebuild
Hot-Plug Support
Cache, Multi-Segmented (MB)
Organic Solderability Preservative Reliability/Data Integrity
Mean Time Between Failures (MTBF, Hours): 2.5 Million
Reliability Rating at Full 24x7 Operation (AFR): 0.35%
Non-Recoverable Read Errors per Bits Read, Max: 1 Sector Per 10E15
Power-On Hours: 8760
512e Sector Size (Bytes per Sector): 512
4Kn Sector Size (Bytes per Sector): 4096 Performance
Spin Speed: 7200 RPM
Interface Access Speed (Gb/s): 6.0, 3.0, 1.5
Max Sustained Transfer Rate OD (MB/s, MiB/s): 254, 243
Average Latency (ms): 4.16
Interface Ports: Single
Rotational Vibration at 1500Hz (rad/s): 12.5 Power Consumption
Idle Average (W): 4.5W
Max Operating Random Write 4K/16Q (W): 6.5
Max Operating, Random Read 4K/16Q (W): 8
Power Supply Requirements: +12V and +5V
PowerChoice Technology: Yes
PowerBalance Technology: Yes Environmental
Temperature, Operating (C): 5 C to 60 C
Vibration, Non-Operating: 10Hz to 500Hz (Gms): 2.27
Shock, Operating 2ms (Read/Write) (GS): 70/40Gs
Shock, Non-Operating 1ms/2ms (Gs): 250Gs Item Dimension (L"xW"xH")
6 x 5 x 1
Weight
1.00 lb
Warranty Information
5 Years
