5 Available
Condition: New
| 80PLUS | Gold |
|---|---|
| Intel form factor compliance | Yes |
| DC to DC converter design | Yes |
| Forward converter circuit | No |
| Fully modular cables | No |
| Fixed cables | Yes |
| 80 mm double ball bearing fan | Yes |
| S3FC - including Fanless mode | No |
| S2FC - Smart and Silent Fan Control | Yes |
| Zero minimum load on 3.3 V rail | Yes |
| Short circuit protection on all outputs | Yes |
| Over voltage protection | Yes |
| Over power protection | Yes |
| 100 % HiPot test | Yes |
| 100 % Burn-in, high temperature cycled on/off | Yes |
| Safety compliance | CB, UL/cUL, TUV, CCC, BSMI, EAC |
| EMC/EMI compliance | CE, FCC, RCM |
| Input frequency | 50 / 60 Hz |
| Inrush current at cold start | 100 A max. |
| Efficiency (at normal input voltage) | Less than or equal to 87% |
| Line regulation | +/- 1 % (typical) |
| Load regulation | +/- 5 % (typical) |
| Cross regulation | +/- 5 % (typical) |
| Ripple / noise | 1 % |
| MTBF, full load at 25 oC ambient (excl. DC fan) | > 100,000 hours |
| Active Power Factor Correction | 99 % (typical) |
| DC Outputs | +3.3 V, 10A, 70W |
| Total continuous power | 300W |
| Input Type | Full range |
| Item Dimension (L inchxW inchxH inch) | 4 x 5 x 3 |
| Weight | 2.60lb |
| Warranty Information | 3 years manufacturer direct warranty |
