Technical Specifications
<b>Processor/Cache</b><br> CPU: <br>- Intel Xeon processor E5-2600 v4/ v3 family (up to 145W TDP) <br>- Dual Socket R3 (LGA 2011) <br>Cores / Cache: Up to 22 Cores / Up to 55MB Cache <br>System Bus: QPI up to 9.6 GT/s <b>System Memory</b><br> Memory Capacity: <br>- 24x 288-pin DDR4 DIMM slots <br>- Up to 3TB ECC 3DS LRDIMM, 512GB ECC RDIMM <br>Memory Type: 2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit <br>DIMM Sizes: <br>- RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB <br>- LRDIMM: 64GB, 32GB <br>- 3DS LRDIMM: 128GB <br>Memory Voltage: 1.2 V <br>Error Detection: Corrects single-bit errors <b>On-Board Devices</b><br> Chipset: Intel C612 chipset <br>SATA: SATA3 (6Gbps), RAID 0, 1, 5, 10 <br>SAS3: Broadcom 3008 SAS3 IT mode <br>IPMI: <br>- Support for Intelligent Platform Management Interface v.2.0 <br>- I-PMI 2.0 with virtual media over LAN and KVM-over-LAN support <br>- ASPEED AST2400 BMC <br>Network Controllers: SIOM support for flexible networking options <br>Graphics: ASPEED AST2400 BMC <b>Input / Output</b><br> LAN: LAN ports via SIOM Add-On-Card <br>USB: 3 USB 3.0 ports (2 rear + 1 Type A) <br>Video: 1 VGA port <br>Serial Port / Header: 1 Fast UART 16550 port / 1 Header <b> Chassis </b><br> Form Factor: 2U Rackmount <br>Model: CSE-826SE1C4-R1K62 <b> Available Colors</b><br> Black <b> Front Panel </b><br>Buttons: <br>- Power On/Off button <br>- System Reset button <br>LEDs: <br>- Power status LED <br>- Hard drive activity LED <br>- 2 Network activity LEDs <br>- System Overheat LED <br>- Power fail LED <b>Expansion Slots </b><br>PCI-Express: <br>- 2 PCI-E 3.0 x16 slots <br>- 1 PCI-E 3.0 x8 slots <b>Drive Bays </b><br>Hot-swap: <br>- 24x 3.5" Hot-swap SAS3/SATA3 drive bays <br>- Optional 2x 2.5" rear Hot-swap SATA drive bays <b>Backplane </b><br>Two 12 port SAS3 12G expander backplanes, each supporting up to 12x 2.5" SAS3 drives <b>System Cooling </b><br>Fans: 5x 8cm hot-swap redundant PWM cooling fans <b>Power Supply </b><br>1600W Redundant Power Supplies with PMBus <br>Total Output Power: 1000W/1600W <br>Input: <br>- 100-127Vac / 13 - 9A / 50-60Hz <br>- 200-240Vac / 10 - 8A / 50-60Hz <br>+12V: <br>- Max: 83.3A / Min: 0A (100-127Vac) <br>- Max: 133A / Min: 0A (200-240Vac) <br>12Vsb: Max: 2.1A / Min: 0A <br>Output Type: 25 Pairs Gold Finger Connector <b>Certification </b><br>UL/cUL/CB/BSMI/CE/CCC <b>System BIOS </b><br>BIOS Type: 128Mb SPI Flash EEPROM with AMI BIOS <br>BIOS Features: <br>- Plug and Play (PnP) <br>- APM 1.2 <br>- PCI 2.2 <br>- ACPI 1.0 / 2.0 <br>- USB Keyboard support <br>- SMBIOS 2.3 <br>- UEFI <b>Operating Environment / Compliance </b><br>RoHS: RoHS Compliant <br>Environmental Spec: <br>- Operating Temperature: 10<sup>o</sup>C to 35<sup>o</sup>C (50<sup>o</sup>F to 95<sup>o</sup>F) <br>- Non-operating Temperature: -40<sup>o</sup>C to 70<sup>o</sup>C (-40<sup>o</sup>F to 158<sup>o</sup>F) <br>- Operating Relative Humidity: 8% to 90% (non-condensing) <br>- Non-operating Relative Humidity: 5% to 95% (non-condensing) <b>Item Dimension (L inchxW inchxH inch)</b><br>NA</b><br><br><b>Weight</b><br>60.00 lb<br><br><b>Warranty Information</b><br>1 Year
