Technical Specifications
Specification: Temperature Range -- Operating: 0°C ~ +50°C on full load; storage & shipping: -20°C ~ +80°C Humidity -- 85% on operating,95% on storage Dielectric Withstand -- Primary frame ground 1800V AC for1 second Efficiency -- typical up to 86% Rise time -- Less than 20ms Hold-up Time -- 20ms minimum at nominal input voltage Power Good Signal -- Power on delay time 100 ~ 500ms, off delay 1ms minimum (TTL and CMOS compatible) Leakage Current -- Less than 3.5mA at 264Vac, 50Hz MTBF -- 100,000 hours on maximum load at +25°C Dimensions (LxWxH) -- 220x100x40.5mm /8.7x3.9x1.6inch Input Characteristics: Input Range -- 90 ~ 264Vac (RMS), Full Range Input Frequency -- 47 ~ 63Hz Input Current -- Max 6.3A (RMS) @ 115Vac, 3A (RMS) @ 230Vac Inrush Current -- No damage. Output Characteristics: Output Voltage: +3.3V, Min. load: 0.5A, Normal Load: 10A, Max. load: 20A , Load Reg: ±5%, Ripple & Noise: 50mV P-P Output Voltage: +5V, Min. load: 0.5A, Normal Load: 10A, Max. load: 20A , Load Reg: ±5%, Ripple & Noise: 50mV P-P Output Voltage: +12V1, Min. load: 1.5A, Normal Load: 8A, Max. load: 16A , Load Reg: ±5%, Ripple & Noise: 120mV P-P
