Technical Specifications
Input Characteristics
Input Range:
90 264Vac, Full Range Input
Frequency:
47 63Hz
Input Current:
Max 5.0A 115Vac, 2.5A 230Vac
Inrush Current:
No Damage Output Characteristics
Output Voltage/ Min Load /Normal Load/ Max Load /Load Reg./ Ripple Noise
+3.3V/ 0.5A/ 12.52A/ 21A/ 5% /50mV P-P
+5V /0.3A/ 8.94A/ 15A / 5%/50mV P-P
+12V1/ 0.5A /10.44A/ 16A / 5%/ 120mV P-P
+12V2 /0.5A /10.44A /16A / 5%/ 120mV P-P
-12V /0.0A /0.25A/ 0.3A/ 10%/ 200mV P-P
+5Vsb/ 0.0A/ 2.09A /2.5A/ 5%/ 50mV P-P Rotational Speed:
140x150x86mm /5.5x5.9x3.4 inch
Storage temp.:
-40C +70C
Operating temp.:
Operating: 0C +25C
MTBF:
100,000 hours on maximum load at +25C
Weight (lbs):
6.00
Item Dimension (L"xW"xH")
5.9 x 3.4 x 5.5
Warranty Information
1 Year
