Technical Specifications
Temperature Range: Operating:
0 C until +50C, storage shipping: -20C until +80C
Humidity:
90% on operating, 95% on storage
Dielectric Withstand:
Primary frame ground 1800V AC for 1 second
Efficiency:
82% minimum
Rise time:
Less than 20ms
Hold-up Time:
17ms minimum at nominal input voltage
Power Good Signal:
Power on delay time 100- 500ms, off delay 1ms minimum (TTL and CMOS compatible)
Leakage Current:
Less than 3.5mA at 264Vac, 50Hz
MTBF:
100,000 hours on maximum load at +25C
Package Dimensions (LxWxH):
150x81.5x40.5mm/ 5.9x3.2x1.6inch
Input Characteristics:
Input Range: 90 - 264Vac (RMS), Full Range Input
Frequency: 47 - 63Hz
Input Current: Max 6A (RMS) at 115Vac, 3A (RMS) at 230Vac
Inrush Current: No damage
Output Characteristics:
Output Voltage: +3.3 V, Minimum Load 0.5A, Maximum Load 16A
Output Voltage: +5 V, Minimum Load 0.5A, Maximum Load 18A
Output Voltage: +12V1, Minimum Load 0.5A, Maximum Load 15A
Output Voltage: +12V2, Minimum Load 0.5A, Maximum Load 15A
Output Voltage: -12 V, Minimum Load 0.0A, Maximum Load 0.5A
Output Voltage: +5Vsb, Minimum Load 0.0A, Maximum Load 3.0A
Weight:
4 lbs
Warranty:
1 year
