Technical Specifications
Features: -- Complied with Flex ATX and ATX12V standard -- Active Power Factor Correction (PFC) meet EN61000-3-2 -- High efficiency and reliability -- Compatible with European Union Directive 2002/95/EC (Restriction on Hazardous Substances). -- Remote ON/OFF function -- Internal 12V DC fan included -- Low noise and ripple -- Output over voltage, short circuit, and over current protection -- 100% Hi-pot, ATE, and burn-in tested -- Re-settable power shut down -- Complies with FCC part 15 subpart J class B 115Vac operation, and CISPR 22 class B at 230Vac operation -- Approved by CUL/UL60950-1, TUV EN60950-1 , NEMKO EN60950-1 (CB Report) CE Input Range -- 90 ~ 265Vac (RMS), Full Range Input Frequency -- 47 ~ 63Hz Input Current -- Max 4A (RMS) @ 115Vac, 2A (RMS) @ 230Vac Inrush Current -- No damage. Output Characteristics: -- Output Voltage: +3.3V, Min. load: 0.3A, Normal Load: 7A, Max. load: 14A , Load Reg: ±5%, Ripple & Noise: 50mV P-P -- Output Voltage: +5V, Min. load: 0.3A, Normal Load: 8A, Max. load: 16A , Load Reg: ±5%, Ripple & Noise: 50mV P-P
