Technical Specifications
Input Characteristics
Input Range:
90 - 264Vac (RMS), Full Range Input
Frequency:
47 - 63Hz
Input Current:
Max 4A (RMS) at 115Vac, 2A (RMS) at 230Vac
Inrush Current:
No damage. Dielectric Withstand:
Primary frame ground 1800V AC for 1 second
Efficiency:
68% minimum.
Rise time:
Less than 20ms Hold-up Time:
17ms minimum at nominal input voltage
Power Good Signal:
Power on delay time 100 - 500ms, off delay 1ms minimum (TTL and CMOS compatible)
Leakage Current:
Less than 3.5mA at 264Vac, 50Hz
MTBF:
100,000 hours on maximum load at +25C Output Characteristics
Output Voltage/ Minimum Load /Normal Load /Maximum Load /Load Reg./ Ripple and Noise
+3.3V /0.3A /5A/ 10A/ +/- 5% /50mV P-P
+5V /0.3A /6.5A /13A/ +/- 5% /50mV P-P
+12V1/ 1.0A /5A/ 10A/ +/- 5% /120mV P-P
-12V /0.0A /0.25A /0.5A /+/- 10% /120mV P-P
+5Vsb/ 0.0A /1.00A /2.0A /+/- 5% /50mV P-P Item Dimension (L"xW"xH"):
6 x 3.2 x 1.6
Weight:
2.25 lb
Warranty Information:
1 Year
