Technical Specifications
OUTPUT
Output Volt Amp Capacity (VA):1000
Output kVA Capacity (kVA):1
Output Watt Capacity (Watts):800
Power Factor:0.8
Nominal Output Voltage(s) Supported:120V
Frequency Compatibility:60 Hz Output Voltage Regulation (Line Mode):-21%, +8%
Output Voltage Regulation (Battery Mode):+/- 5%
UPS Output Receptacles:6 5-15R outlet(s)
Load Management Receptacles:Two switchable two-outlet 5-15R load banks
Output AC Waveform (AC Mode):Sine wave
Output AC Waveform (Battery Mode):Pure Sine wave INPUT
Rated input current (Maximum Load):9.2A
Nominal Input Voltage(s) Supported:120V AC
UPS Input Connection Type:5-15P
Input Circuit Breakers:10A UPS Input Cord Length (ft.):10
UPS Input Cord Length (m):3
Recommended Electrical Service:15A 120V
Input Phase:Single-Phase BATTERY
Full Load Runtime (min.):5.3 min. (800w)
Half Load Runtime (min.):15 min. (400w)
DC System Voltage (VDC):24
Battery Recharge Rate (Included Batteries):Less than 4 hours from 10% to 90%
Internal UPS Replacement Battery Cartridge:See Tripp Lite UPS Battery Selector
Battery Access:Front panel battery access door
Battery Replacement Description:Hot-swappable, user replaceable batteries VOLTAGE REGULATION
Voltage Regulation Description:Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147
Overvoltage Correction:Input voltages between 128 and 147 are reduced by 12%
Undervoltage Correction:Input voltages between 83 and 107 are boosted by 14% LEDS ALARMS and SWITCHES
Front Panel LCD Display:Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual for detailed LCD configuration and monitoring options) Audible Alarm:Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions Alarm Cancel Operation:Power-fail alarm can be temporarily silenced using alarm-cancel switch silent mode alarm configuration option available Switches:3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions SURGE / NOISE SUPPRESSION
UPS AC Suppression Joule Rating:570
UPS AC Suppression Response Time:Instantaneous
EMI / RFI AC Noise Suppression:Yes
Cooling Method:Fan
UPS Housing Material:Steel COMMUNICATIONS
Communications Interface:USB (HID enabled) DB9 Serial EPO (emergency power off) Slot for SNMP/Web interface
Network Monitoring Port Description:Supports detailed monitoring of UPS and site power conditions
PowerAlert Software:Included
Communications Cable:USB and DB9 cabling included WatchDog Compatibility:Supports Watchdog application, OS and hard-reboot restart options for remote applications
Network UPS Tools Compatibility:NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.htmlmanufacturerTripp Lite LINE / BATTERY TRANSFER
Transfer Time:2-4 milliseconds
Low Voltage Transfer to Battery Power (Setpoint):83
High Voltage Transfer to Battery Power (Setpoint):147 SPECIAL FEATURES
Grounding Lug:Back panel grounding lug
Cold Start (Startup in Battery Mode During a Power Failure):Cold-start operation supported
High Availability UPS Features:Hot swappable batteries
Green Energy-Saving Features:Individually controllable load banks Item Dimension (L"xW"xH"):
22.9 x 19.3 x 7.9
Weight:
46.4 lb
Warranty Information:
2-year limited warranty
