SCM-SLF-WBR-WH - Shadow-caster Led Lighting Shadow-Caster SCM-SL Series Flush Mount Spreader Light - White Housing - Whi

SCM-SL Series Flush Mount Spreader Light - White Housing - White/Blue/Red

The Shadow-Caster Spreader Light is perfect for illuminating decks and other large areas of your boat or yacht. The flush mount version is great for mounting in T-Tops or use the bracket mount version to retrofit existing installations. The Shadow-Caster Spreader Light has a unique reflector design that spreads the light beams out to reduce glare. The Spreader Light comes in a black or white finish. It is available in 3 color output options: single color white, 2 colors (white and blue) as well as a full-color version. The brightness and color can be controlled with a standard switch.

Features:

• Soft start technology ramps the brightness up gently over 2 seconds.
• Power toggle feature to set brightness and change color
• True white LED for best color performance
• High-efficiency switch mode power supply
• Waterproof low-profile aluminum housing
• White or black finish
• Unique reflector design to reduce glare

Specifications:

• 1500 lumen output
• 60-degree beam angle
• 16-watt power draw
• 10-30 volts Input
• 1.4A at 12 volts, 0.7A at 24 volts
• 6200 Kelvin cool white color temperature
• 5” (127mm) overall width x 1.5”(38mm) height x 1.3” (33mm) mounting depth.
• IP67 waterproof design
• Durable glass lens
• The full-color version includes Shadow-NET® interface for controlling color

Includes:

• Spreader light
• Mounting screws and (2 screws) #4 X 0.5” SS3160H screws with flush mount version
• Quick start guide
• Standard 2 year warranty

The Shadow-Caster SCM-SL Series Flush Mount Spreader Light, part number SCM-SLF-WBR-WH, is a dedicated lighting solution for marine environments. This unit is designed to illuminate decks and other expansive areas on boats and yachts, providing 1500 lumens of output with a 60-degree beam angle. Its flush-mount design is suitable for integration into T-Tops, offering a low-profile installation. The light features a white aluminum housing and outputs white, blue, and red light, controllable via a standard switch. A unique reflector design aims to minimize glare, enhancing visibility without excessive brightness. With a 10-30 volt input range and an IP67 waterproof rating, this light is built for demanding marine conditions. It includes soft start technology for gentle illumination and a power toggle feature for brightness and color adjustments. This product is intended for marine professionals and boat owners requiring reliable, multi-color area lighting.
