Technical Specifications
Output
Output power capacity:280Watts / 450VA
Max Configurable Power (Watts):280Watts / 450VA
Nominal Output Voltage:120V
Output Frequency (sync to mains):50/60Hz +/- 3 Hz
Load Crest Factor:--
Topology:Line Interactive
Waveform type:Stepped approximation to a sinewave
Output Connections:(4) NEMA 5-15R (Battery Backup)
Transfer Time:4ms typical : 8ms maximum
Input
Nominal Input Voltage:120V
Input frequency:50/60 Hz +/- 3 Hz (auto sensing)
Input Connections:NEMA 5-15P
Cord Length:6ft ( 1.83meters )
Input voltage range for main operations:82 - 144V
Input voltage adjustable range for mains operation:75 - 154V
Number of Power Cords:1
Batteries Runtime
Battery type:Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time:5hour(s)
Replacement Battery:RBC18
Expected Battery Life (years):3 - 5
RBC Quantity:1
Runtime:View Runtime Graph
View Runtime Chart
Efficiency:View Efficiency Graph
Communications Management
Interface Port(s):DB-9 RS-232
Control panel:LED status display with On Line : On Battery : Replace Battery and Overload indicators
Audible Alarm:Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating:412Joules
Filtering:Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Rack Height:1U
Color:Grey
Environmental
Operating Environment:32 - 104 oF ( 0 - 40 oC )
Operating Relative Humidity:0 - 95 %
Operating Elevation:0-10000ft ( 0-3000meters )
Storage Temperature:-15 - 45 oC
Storage Relative Humidity:0 - 95 %
Storage Elevation:0-50000ft ( 0-15000meters )
Audible noise at 1 meter from surface of unit:38.0dBA
Online thermal dissipation:38.0BTU/hr
Conformance
Approvals:CSA, FCC Part 15 Class A, UL 1778 Sustainable Offer Status
RoHS:Compliant
PEP:Available in Documentation tab
EOLI:Available in Documentation tab
Item Dimension (L inchxW inchxH inch)
24 x 19 x 7 Weight
28.50lb Warranty Information
2 years repair or replace
