Supermicro SBI-7128R-C6(3YR) SuperBlade SBI-7128R-C6 Server Barebone System - Blade - Socket LGA 2011-v3 - 2 x Processor

Motherboard
Super B10DRC Processor/Cache
CPU
Intel Xeon processor E5-2600 v4/ v3 family
Dual Socket R3 (LGA 2011)
Cores / Cache
Up to 22 Cores / Up to 55MB Cache
System Bus
QPI up to 9.6 GT/s
Note
BIOS version 2.0 or above is required
System Memory
Memory Capacity
16x 288-pin DDR4 DIMM slots
Up to 2TB ECC LRDIMM, 512GB ECC RDIMM
Memory Type
2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
DIMM Sizes
RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
3DS LRDIMM: 128GB
Memory Voltage
1.2 V
Error Detection
Corrects single-bit errors
On-Board Devices
Chipset
Intel C612 Express chipset
InfiniBand Support
4x FDR-10/QDR (40Gbps) InfiniBand or 10GbE mezzanine HCA (Optional)
SAS
Broadcom 3108 SAS3 (12Gbps) controller
HW RAID 0, 1, 5, 50, 6 support
IPMI
Support for Intelligent Platform Management Interface (IPMI) v.2.0 via Chassis Management Module (CMM)
Network Controllers
Intel I350 Dual port Gigabit Ethernet
Intel I/OAT 3 support for fast, scaleable, and reliable networking
VMDq support for better performance of virtualization
Graphics
Aspeed AST2400 BMC
System BIOS
BIOS Type
128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features
Plug and Play (PnP)
PCI 2.2
ACPI up to 3.0
USB Keyboard support
Available Colors
Black
Front Panel
Buttons
Power On/Off button
KVM button
LEDs
Power LED
UID / KVM LED
Network Activity LED
Fault LED
Connector
SUV (Serial/USB/Video) and KVM Connector
Drive Bays
Hot-swap
6x 2.5" Hot-swap SAS/SATA/SSD bays
Input / Output
DOM
2x SuperDOM (Disk on Module) ports
TPM
1x TPM 1.2 20-pin Header
KVM
1x Front Connector for SMCI KVM Card
Operating Environment / Compliance
Environmental Spec.
Operating Temperature: 10^oto 35^oC (50^oto 95^oF)
Non-operating Temperature: -40^oto 70^oC (-40^oto 158^oF)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5 to 95% (non-condensing)
Electromagnetic Compatibility (EMC)
United States / Canada
FCC- Emissions (US) Verification
Europe
EN55022 - Emissions
EN55024 - Immunity
EN61000-3-2 - Harmonics
EN61000-3-3 - Voltage Flicker
CE - EMC Directive 89/336/EEC
Safety Compliance
United States / Canada
UL60950-1 - CSA/CUL 60950-1
Europe
EN60950-1, CE - Low Voltage Directive 73/23/EEE
Germany
TUV
Thermal Limitation
Note
SuperBlade full enclosure with four 1620W power supplies will have thermal limitation of 30^oC ambient temperature.
Item Dimension (L"xW"xH")
21 x 12 x 2
Weight
8.60 LB
Warranty Information
3 years
