S8036GM2NE - Tyan MOTHERBOARD S8036GM2NE, AMD, 2 PCLE 4.0 RISER SLOTS

Processor
Qty / Socket Type
(1) AMD Socket SP3
Supported CPU Series
(1) AMD EPYC^TM 7002 Series Processor
Configurable Thermal Design Power (cTDP) Wattage
Max up to 240W Memory
Supported DIMM Qty
(16) DIMM slots
DIMM Type / Speed
DDR4 ECC RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS 3200
Capacity
Up to 2,048GB RDIMM / 4,096GB LRDIMM 3DS
Memory channel
8 Channels per CPU
Memory voltage
1.2V Expansion Slots
PCI-E
(1) PCI-E Gen4 x 24 slot / (1) PCI-E Gen4 x 24 slot (w/x16 link, can be x24 link if OCP mezz. conn.B is not used. Please contact with Tyan technical support for details.)
Recommended TYAN Riser Card (PCI-E Gen4)
M8036-L24-3F, 2U riser card for slot number 6 w/ (3) PCI-E slots (left) / M8036-R24-3F, 2U riser card for slot number 6.5 w/ (3) PCI-E slots (right)
Others
(1) PCI-E Gen3 x16 OCP 2.0 slot (conn.A+conn.B) LAN
Qty / Port
(2) GbE ports + (1) GbE dedicated for IPMI
Controller
Broadcom BCM5720
PHY
Realtek RTL8211E Storage
SATA
Connector
(2) SFF-8654 connectors for up to (16) SATA ports
Controller
Direct from AMD EPYC CPU
Speed
6Gb/s
RAID
N/A
Additional SATA
Connector
(2) SATA-DOM / (2) SATA
Controller
Marvell 9235
Speed
6Gb/s
RAID
N/A
NVMe
Connector (M.2)
(2) 22110/2280 (by PCI-E Gen3 and SATA interface)
Connector (Slim SAS)
(8) SFF-8654 for (16) NVMe ports Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500 Input /Output
USB
(2) USB3.1 Gen1 ports (at rear) / (2) USB3.1 Gen1 ports (via Cable) / (1) USB3.1 Gen1 port (Type-A)
COM
(1) DB-9 COM Connector (at rear, COM1) + (1) Header (COM2)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(2) GbE ports / (1) GbE dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(2) SATA-III connectors + (2) SATA-DOM connectors + (16) SATA ports from (2) Slim SAS connectors
Power
SSI 24-pin + 8-pin + 8-pin power connectors TPM (Optional)
TPM Support
Please refer to our TPM supported list. System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU and memory and system environment
Voltage
Monitors voltage for CPU, memory, chipset and power supply
LED
Fan fail LED indicator / Over temperature warning indicator / Fan and PSU fail LED indicator
Others
Watchdog timer support Server Management
AST2500 iKVM Feature
24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2500 IPMI Feature
IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface BIOS
Brand / ROM size
AMI / 32MB
Feature
Hardware Monitor / SMBIOS 3.0/PnP/Wake on LAN / Boot from USB device/PXE via LAN/Storage / Console Redirection / ACPI 6.1 / ACPI sleeping states S0, S5 / FAN speed control automatic Form Factor
EATX Regulation
FCC (SDoC)
Class A
CE (DoC)
Class A Operating Environment
Operating Temp.
10^oC to 35^oC (50^oFto 95^oF)
Non-operating Temp.
- 40^oC to 70^oC (-40^oF to 158^oF)
In/Non-operating Humidity
90%, non-condensing at 35^oC RoHS
RoHS 6/6 Compliant
Yes Operating System
OS supported list
Please refer to our AVL support lists. Package Contains
Motherboard
(1) S8036 Motherboard
Manual
(1) Quick Installation Guide
I/O Shield
(1) I/O Shield
Cable
SATA
(2) SATA signal cables Weight
3.00 LB

Warranty Information
1 Year
