S8026GM2NRE - Tyan AMD EPYC / PCIE X24 & X16 / OCP 2.0

Special Order
Ships in 1-2 weeks
Condition: New

$724.72  $978.37
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

The TYAN S8026 Motherboard is designed to support the powerful AMD EPYC 7000 Series processors. This EATX form factor motherboard features advanced architecture for high-performance computing, ideal for data centers and enterprise applications. Equipped with multiple expansion slots and extensive memory support, it delivers exceptional flexibility and scalability for demanding workloads.

Technical Specifications

  • Processor: Supports AMD Socket SP3 with an ACP wattage of up to 180W.
  • Memory: 16 DIMM slots supporting up to 1024GB DDR4 ECC RDIMM/LRDIMM with 8 channels.
  • Expansion Slots: Multiple PCI-E slots including Gen3 x24 and x16 for enhanced connectivity.
  • Networking: Two GbE ports plus one dedicated for IPMI, utilizing Broadcom and Realtek controllers.
  • Storage: Features multiple M.2 connectors and PCI-E OCuLink connectors for NVMe and SATA interfaces.
  • Graphics: Built-in Aspeed AST2500 chipset supporting D-Sub 15-pin with a maximum resolution of 1920x1200.
  • USB Ports: Includes various USB 3.0 and 2.0 ports for connectivity.
  • Management: IPMI 2.0 compliant BMC with remote management capabilities.
  • Dimensions: EATX form factor with dimensions of 12" x 13" (305x330mm).
  • Operating Conditions: Supports an operating temperature range of 10°C to 35°C.
  • Warranty: Backed by a 3-year warranty for peace of mind.

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Country of Origin:
  • TYAN
  • S8026GM2NRE
  • 635872043710
  • New
  • 7 lbs
  • 12 X 5 X 13
  • Jun 13, 2026
  • Mar 02, 2020
  • NN
Product Identifiers: Brand: Tyan • Part #: S8026GM2NRE • UPC: 635872043710 • Category: Motherboard Components
