Tyan S7103WGM4NR-2F-L2 Motherboard S7103WGM4NR-2F-L2 CX S7103 Dual Intel Xeon Scalable C622 LGA3647 DDR4 Retail

Processor
Qty / Socket Type:(2) LGA3647
Supported CPU Series:Intel Xeon Scalable Processor
Thermal Design Power (TDP) Wattage:Max up to 205W
System Bus:Up to 10.4/9.6 GT/s with Intel UltraPath Interconnect (UPI) support
Chipset
PCH:Intel C622
Memory
Supported DIMM Qty:(6)+(6) DIMM slots
DIMM Type / Speed:DDR4 ECC RDIMM/LRDIMM 2666/2400/2133
Capacity:Up to 384GB RDIMM/ 768GB LRDIMM/ 1,536GB RDIMM 3DS/LRDIMM 3DS Follow latest Intel DDR4 Memory POR
Memory channel:6 Channels per CPU
Memory voltage:1.2V
Expansion Slots
PCI-E:(2) PCI-E Gen3 x16 slots / (5) PCI-E Gen3 x8 slots
LAN
Qty / Port:(2) 10GbE ports, (2) GbE ports, (1) PHY dedicated for IPMI
Controller:Intel I350-AM2 / Intel C622 PCH
PHY:Realtek RTL8211E
Storage
SAS:Connector:(2) Mini-SAS HD connectors (totally support 8 ports)
Controller:LSI SAS3008
Speed:12.0 Gb/s
RAID:RAID 0/1/10 (LSI Integrated RAID)
SATA:Connector:(2) Mini-SAS (8-ports)
Controller:Intel C622
Speed:6.0 Gb/s
RAID:RAID 0/1/10/5 (Intel RSTe)
sSATA:Connector:(1) Mini-SAS (4-ports) / (2) SATA-DOM
Controller:Intel C622
Speed:6.0 Gb/s
RAID:RAID 0/1/10/5 (Intel RSTe)
Graphic
Connector type:D-Sub 15-pin
Resolution:Up to 1920x1200
Chipset:Aspeed AST2500
Input /Output
Others:(1) ID button
USB:(2) USB3.0 ports (via cable) / (2) USB3.0 ports (at rear) / (1) Type-A USB3.0 port
COM:(1) DB-9 COM Connector
VGA:(1) D-Sub 15-pin VGA port (at rear)
RJ-45:(2) GbE ports, (1) Dedicated for IPMI
Front Panel:(1) 2x12-pin SSI front panel header
SATA:(2) SATA/SATA-DOM connectors + (3) Mini-SAS (4-in-1) connectors
Power:SSI/ATX 24-pin + 8-pin power connectors
SFP+:(2) 10GbE ports
TPM (Optional)
TPM Support:Please refer to our TPM supported list.
System Monitoring
Chipset:Aspeed AST2500
Fan:Total (1) 2 x 10-pin headers
Temperature:Monitors temperature for CPU and memory and system environment
Voltage:Monitors voltage for CPU, memory, chipset and power supply
LED:Over temperature warning indicator / Fan and PSU fail LED indicator
Others:Watchdog timer support
Server Management
AST2500 iKVM Feature:24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2500 IPMI Feature:IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size:AMI / 32MB
Feature:Hardware Monitor / ACPI 5.0 / SMBIOS 3.0/PnP/Wake on LAN / Boot from USB device/PXE via LAN/Storage / User Configurable FAN PWM Duty Cycle / Console Redirection / ACPI sleeping states S0,S1,S5
Regulation
FCC (DoC):Class A
CE (DoC):Class A
Operating Environment
Operating Temp.:10^o C to 35^o C (50^o Fto 95^o F)
Non-operating Temp.:- 40^o C to 70^o C (-40^o F to 158^o F)
In/Non-operating Humidity:90%, non-condensing at 35^o C
RoHS
RoHS 6/6 Compliant:Yes
Operating System
OS supported list:Please refer to our AVL support lists.
Package Contains
Motherboard:(1) S7103 Motherboard
Manual:(1) Quick Installation Guide
Installation CD:(1) TYAN Device Driver CD
Item Dimension (L inchxW inchxH inch)
12 x 13 x 1 Weight
3.00lb Warranty Information
3 Years
