Technical Specifications
Processor
Socket Type / Qty
LGA2011 / (1)
Supported CPU Series
Intel Xeon Processor E5-2600/E5-1600 v3/v4 series processors
Thermal Design Power (TDP) Wattage
Max up to 160W
Chipset
PCH
Intel C612
Memory
Supported DIMM Qty
(8) DIMM slots
DIMM Type / Speed
RDIMM DDR4 2400/2133/1600 / LRDIMM DDR4 2400/1866 / LRDIMM 3DS DDR4 2400/1866 (Up to 2400 speed support only w/E5-2600 v4)
Capacity
Up to 256GB RDIMM/ 512GB LRDIMM/ 1,024GB LRDIMM 3DS Follow latest Intel DDR4 Memory POR
Memory channel
4 Channels per CPU
Memory voltage
1.2V
Expansion Slots
PCI-E(1) PCI-E Gen3 x16 slot
Recommended TYAN OCP Card
M7062-B811-1T, PCI-E Gen3 x8, Broadcom 10GbE Mezz Card / M7062-B810-2T, PCI-E Gen3 x8, Broadcom 10GbE Mezz Card / M7076-X540-2T, PCI-E Gen3 x8, Intel 10GbE Mezz Card / M7076-I350, PCI-E Gen3 x8, Intel (2)GbE Mezz Card / M7062-I599-1T, PCI-E Gen3 x8, Intel 10GbE Mezz Card / M7062-I599-2T, PCI-E Gen3 x8, Intel 10GbE Mezz Card
NOTE:
(1) OCP slot for Mezz Card
LAN
Qty / Port
(2) GbE ports (1 port shared with IPMI)
Controller
Intel I210-AT
Storage
SATA
Connector
(6) SATA
Controller
Intel C612
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel RSTe)
sSATA
Connector
(1) Mini-SAS (4-ports)
Controller
Intel C612
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel RSTe)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2400
Input /Output
USB
(4) USB 2.0 ports (2 at rear, 2 via cable) / (5) USB3.0 ports (2 at rear, 2 via cable, Type-A)
COM
(2) ports (1 at rear, 1 via cable)
VGA
(1) D-Sub 15-pin VGA port (at rear)
