Tyan S5542WGM4NR Motherboard S5542WGM4NR E3-1200v6/v5 LGA1151 C232 Max.64GB PCI Express SATA ATX Retail

Processor
Socket Type / Qty: LGA1151 / (1)
Supported CPU Series: Intel Xeon processor E3-1200 v6/v5 product family / 7th/6th Gen. Intel Core i3 Processors / Intel Celeron and Intel Pentium
Thermal Design Power (TDP) wattage: Max up to 80W Chipset
PCH: Intel C232 Memory
Supported DIMM Qty: (4) DIMM slots
DIMM Type / Speed: Unbuffered ECC UDIMM DDR4 2133/2400
Capacity: Up to 64GB
Memory channel: 2 Channels
Memory voltage: 1.2V Expansion Slots
PCI-E: (1) PCI-E Gen.3 x16 slot (w/ x8 link) / (2) PCI-E Gen.3 x1 slot LAN
Port Qty: (4) ports + (1) dedicated for IPMI
Controller: Intel I210-AT
PHY: Broadcom BCM5221 PHY (dedicated for IPMI connection) Storage
SAS Connector: (2) Mini-SAS HD connectors (totally support 8 ports)
SAS Controller: LSI SAS3008
SAS Speed: 12.0 Gb/s
SAS RAID: RAID 0/1/1E/10 (LSI Integrated RAID)
SATA Connector: (6) SATA
SATA Controller: Intel C232
SATA Speed: 6.0 Gb/s
SATA RAID: RAID 0/1/10/5 (Intel RSTe) Graphic
Connector type: D-Sub 15-pin
Resolution: Up to 1920x1200
Chipset: Aspeed AST2400 Input /Output
USB: (3) USB2.0 ports (2 via cable, 1 Type-A) / (6) USB3.0 ports (4 at rear, 2 via cable)
COM: (2) ports (1 at rear, 1 via cable)
VGA: (1) D-Sub 15-pin VGA port
RJ-45: (2) GbE ports, (1) Dedicated for IPMI
SAS: (2) Mini-SAS HD (4-in-1) connectors
SATA: (6) SATA-III connectors
PSMI: (1) 1x5-pin header
Others: (1) Reset button/ (1) Power button TPM Module
Interface: 2 x 8 pin header System Monitoring
Chipset: Aspeed AST2400
Fan: Total (4) 4-pin headers
Temperature: Monitors temperature for CPU memory system environment
Voltage: Monitors voltage for CPU, memory, chipset power supply
LED: Over temperature warning indicator / Fan PSU fail LED indicator
Others: Watchdog timer support Server Management
Onboard Chipset: Onboard Aspeed AST2400
AST2400 IPMI Feature: IPMI 2.0 compliant baseboard management controller (BMC) / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2400 iKVM Feature: 24-bit high quality video compression / 10/100 Mb/s MAC interface BIOS
Brand / ROM size: AMI / 16MB
Feature: Hardware Monitor / ACPI 5.0 / SMBIOS 3.0/PnP/Wake on LAN / ACPI sleeping states S3,S4,S5 / Boot from USB device/PXE via LAN/Storage / User Configurable FAN PWM Duty Cycle / Console Redirection Physical Dimension
Form Factor: ATX
Board Dimension: 12"x9.6" (305x243.8mm) Regulation
FCC (DoC) : Class A
CE (DoC) : Yes Operating Environment
Operating Temp. : 10^oC to 35^oC (50^oF to 95^oF)
Non-operating Temp. : - 40^oC to 70^oC (-40^oF to 158^oF)
In/Non-operating Humidity: 90%, non-condensing at 35^oC RoHS
RoHS 6/6 Compliant: Yes Operating System
OS supported list: Please refer to our AVL support lists. Package Contains
Motherboard: (1) S5542 Motherboard
Manual: (1) Web Users manual / (1) Quick Installation Guide
Installation CD: (1) TYAN installation CD Item Dimension (L inchxW inchxH inch)
12 x 10 x 2

Weight
3.00 lb

Warranty Information
3 Year
