S452-Z30 - Gigabyte 4U UP AMD EPYC 7002 CPU 16 DDR4

4U

Motherboard
MZ32-AR0

CPU
AMD EPYC^TM 7002 series processor family
Single processor, 7nm, Socket SP3
Up to 64-core, 128 threads per processor
cTDP up to 180W
Compatible with AMD EPYC^TM 7001 series processor family

Socket
Socket SP3

Chipset
System on Chip

Memory
16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
Memory speed: Up to 3200/ 2933 MHz
- Note:
Follow BIOS setting and memory QVL list if running 3200 Mhz with 2DPC

LAN
2 x 1GbE LAN ports (1 x Intel I350-AM2)
1 x 10/100/1000 management LAN

Video
Integrated in Aspeed AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200 at 60Hz 32bpp, DDR4 SDRAM

Audio
-

Storage
Front side: 24 x 3.5" or 2.5" SATA/SAS hot-swappable HDD/SSD bays
Rear side: 12 x 3.5" or 2.5" SATA/SAS hot-swappable HDD/SSD bays
Rear side bays:
2 x 2.5" SATA/SAS hot-swappable SSD bays
4 x 2.5" SATA/SAS/NVMe hybrid hot-swappable SSD bays
NOTE:
Rear side 2.5" bays support Solid State Drives only due to thermal consideration
1 x Broadcom SAS35x48 expanders
Bandwidth: SATAIII 6Gb/s or SAS 12Gb/s per port
Default configuration supports:
2 x SATA/SAS and 4 x SATA/SAS/NVMe devices available in rear side
SAS card is required to enable the drive bays
Suggested 12Gb/s SAS cards:
CRA4648
CSA4648
2 x M.2 slots:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2242/2260/2280 cards

SATA
Yes, enterprise devices only

SAS
Depends on SAS add-on Card

RAID
Depends on SAS add-on Card

Peripheral Drives
-

Expansion Slots
Slot_6: 1 x PCIe x16 (Gen4 x16 bus) slot
Slot_5: 1 x PCIe x16 (Gen4 x8 bus) slot
Slot_4: 1 x PCIe x16 (Gen4 x16 bus) slot
Slot_3: 1 x PCIe x16 (Gen4 x16 bus) slot
Slot_2: 1 x PCIe x8 (Gen3 x0 or x8 bus) slot
Slot_1: 1 x PCIe x16 (Gen3 x16 or x8 bus) slot shared with slot_2
1 x OCP mezzanine slot with PCIe Gen3 x16 bandwidth (Type1, P1, P2, P3, P4)

Internal I/O
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
10 x SlimSAS connectors
2 x M.2 slots
1 x CPU fan headers
5 x System fan headers
1 x USB 3.0 header
1 x USB 2.0 header
1 x COM_2 header
1 x TPM header
1 x Front panel header
1 x HDD back plane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
1 x Buzzer

Front I/O
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x System status LED
2 x LAN activity LEDs

Rear I/O
3 x USB 3.0
1 x VGA
1 x COM_1
2 x RJ45
1 x MLAN
1 x ID button with LED

Backplane I/O
3.5" HDD/SSD bays bandwidth: SATA 6Gb/s or SAS 12Gb/s per port
2.5" HDD/SSD bays bandwidth: SATA 6Gb/s or SAS 12Gb/s or NVMe PCIe x4 per port

TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
