Technical Specifications
Device Type
LED-backlit LCD monitor : 24"
Diagonal Size
24"
Features
Arsenic-free glass and mercury-free panel
Panel Type
IPS
Aspect Ratio
16:09
Native Resolution
1920 x 1080 at 60Hz
Pixel Pitch
0.2745mm x 0.2745mm
Brightness
400 cd/m2 (typ) , 600 cd/m2 (peak)
Contrast Ratio
1,000:1 (typical)
Response Time
5ms (fast), 8ms (normal)
Color Support
16.7 million colors
Input Connectors
2x HDM 2.0
1x Analog 2.0 Audio Line-Out (3.5mm jack)
Display Position Adjustments
Tilt
Screen Coating
Anti-glare treatment of front polarizer (3H)
Compliant Standards
RoHS
Diagonal Viewing Size
60.45 cm
23.8 inches
Maximum Preset Resolution
1920 x 1080 at 60 Hz
Color gamut
DCI-P3 1976 coverage >85%
sRGB 1931 coverage >99%
Displayable Colors
16.7 million colors
Connectivity
2x HDMI-in 2.0
1x Analog 2.0 Audio Line-Out (3.5mm jack) HDR-ready
Yes
Narrow bezels
Yes, Dell InfinityEdge design Bezel dimensions (L/R, T/B)
5.2 mm / 5.2 mm, 5.2 mm / 7.7 mm
0.20" / 0.20", 0.20" / 0.30"
Power Consumption (Operational)
20W (typ) to 33W (max)
Power Consumption (Active Off)
Less than 0.5W
Power Consumption (Switched Off)
Less than 0.3W
Voltage Required
cFR/BFR/PVC-reduced
Backlight Technology
White LED, EDGELIGHT system
Viewing angle
178o vertical / 178o horizontal
Active Viewing Area (HxV)
527.04 mm x 296.46 mm
20.75" x 11.67"
Viewable screen area (HxV)
156,246.28 mm2
242.18 inches2
Pixel Per Inch (PPI)
93 HDCP support
Yes, HDCP 2.2 (combine HDMI 1.4 with HDCP 1.4)
Tilt Angles
-5o to 21o
Temperature Range
Operating: 0oC to 40oC (32oF to 104oF)
Non-operating: -20oC to 60oC (-4oF to 140oF)
Humidity Range
Operating: 10% to 80% (non-condensing)
Non-Operating: 5% to 90% (non-condensing)
Altitude
Operating: 5,000 m (16,404 ft) max
Non-Operating: 12,192 m (40,000 ft) max
Dell Display Manager Compatibility
Yes, complete with Dell EasyArrange
Whats in the box
Monitor with stand
1x Power cable
1x Power adapter
1x HDMI 2.0 cable
Quick setup guide
Safety, Environmental, and Regulatory Information
Compliance and Standards
ENERGY STAR certified
EPEAT Silver
TCO-certified
RoHS compliant
CFR/BFR/PVC-reduced
