Technical Specifications
Storage
Drive Bays: 12
Compatible Drive Type:
- 3.5" SAS HDD
- 2.5" SAS HDD
- 2.5" SAS SSD
Maximum Internal Raw Capacity: 96 TB (8 TB HDD X 12) (Capacity may vary by RAID types)
Hot Swappable Drives: Yes
RAID Management Through Synology DSM: Yes External Ports
MiniSAS IN-Port: 2
MiniSAS OUT-Port: 2 Power
Power Recovery: Synchronized with the Synology RackStation
Power Supply Unit/Adapter: 2 x 500W
AC Input Power Voltage: 100V to 240V AC
Power Frequency: 50/60 Hz, Single Phase
Power Consumption: 248W (Access)
British Thermal Unit: 846.21 BTU/hr (Access)
Redundant Power Supply: Yes Temperature
Operating Temperature: 5 C to 35 C (40 F to 95 F)
Storage Temperature: -20 C to 60 C (-5 F to 140 F)
Relative Humidity: 5% to 95% RH Others
System Fans: 60mm x 60mm x 4pcs
Easy Replacement System Fan: Yes
Noise Level: 48 dB(A)
Certification: FCC Class A, CE Class A, BSMI Class A Environment and Packing
Environment: RoHS
Optional Accessories: Synology RKS1314 - Rail Kit Sliding Package Contents
1 x Main Unit
1 x Accessory Pack
2 x AC Power Cord
2 x Expansion Cable: MiniSAS
1 x Quick Installation Guide Item Dimension (LxWxH)
34 x 26 x 10
weight
64.00 lb
Warranty Infotmation
5 Years
