Technical Specifications
Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6
Product Segment
AC5300 ultimate AC performance:1000+2167+2167 Mbps
Coverage
Very large homes
Data Rate
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 600 Mbps
802.11ac : up to 1734 Mbps
1024QAM (2.4GHz) : up to 1000 Mbps
1024QAM (5GHz) : up to2167 Mbps
Antenna
External antenna x 8
Transmit/Receive
MIMO technology
2.4 GHz 4 x 4
5 GHz-1 4 x 4
5 GHz-2 4 x 4
Memory
128 MB Flash
512 MB RAM
Wi-Fi Technology
Beamforming: standard-based and universal 1024-QAM high data rate
20/40/80 MHz bandwidth
Operating Frequency
2.4G Hz, 5 GHz-1, 5 GHz-2
Encryption
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , Radius with 802.1x, WPS support
Firewall and Access Control
Firewall:SPI intrusion detection,DoS protection
Access control:Parental control, Network service filter, URL filter, Port filter
Management
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, SNMP, NTP Client, DDNS, Port Trigger, Virtual Server, DMZ, System Event Log
WAN Connection Type
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Ports
RJ45 for 10/100/1000 BaseT for WAN x 1, RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4
USB 2.0 x 1
USB 3.0 x 1
Button
WPS Button, Reset Button, Power Button, Wireless on/off Button
LED Indicator
Power x 1
WAN x 1
LAN x 1
Wireless x 2
WPS x 1
Power Supply
AC Input : 110V240V(5060Hz)
DC Output : 19 V with max. 3.42 A current
Color
Black
Operation mode
Wireless router mode
Access point mode
Item Dimension (L"xW"xH")
10 x 10 x 3
