Technical Specifications
Host Ports
2x Thunderbolt TM 3 Ports I/O Ports
NVMe Storage Adapter Number of Channel / Port
4x M.2 NVMe Ports Number of Devices
4x M.2 NVMe SSDs RAID Mode
Single, RAID 0, 1, 5, 10 Daisy Chain
Support Daisy Chain connections of up to six Thunderbolt TM devices
Note: the Daisy Chain will end if you connect a USB or Display device via USB-C TB3 Technology
Daisy Chain up to 6 devices
Bi-directional, dual-protocol (PCI Express and DisplayPort)
8 lanes of DisplayPort 1.2 supports dual 4K displays or one 5K display
Power delivery 15W to bus-powered devices
Backwards compatible with Thunderbolt TM 2 devices
USB-C ports are compatible with existing USB devices via USB-C cable, support up to USB 3.1 10Gb/s speed
System Requirement
Computer with a USB-C (Thunderbolt TM 3)
Computer with a Thunderbolt TM 2 (via Thunderbolt TM 3 to Thunderbolt TM 2 Adapter)
macOS 10.13 and later
Windows 10 and later
Enclosure Indicator
Power On (Blue)
Chassis Design Features
Rugged, Ultra slim aluminum enclosure
Dual-Ultra Quiet, high-efficiency Cooling fans
Quick release thumbscrews for easy access
Power Supply
External 60 watts power supply Material
Aluminum Power
Input AC 100-240V Output DC 12V 5A MTBF (Mean Time Before Failure)
920,585 Hours Certification / Approval
CE, FCC, RoHS, REACH, WEEE, Thunderbolt TM Item Dimension (L inchxW inchxH inch)
3 x 7 x 11 Weight
6.00lb Warranty Information
1 Year
