Technical Specifications
Host Ports
2x Thunderbolt 3 Ports I/O Ports
2x USB 3.1 Gen 1 type A Ports
2x eSATA Ports Number of Channel / Port
6Gb/s per eSATA Port
5Gb/s Per USB 3.0 Port Number of Devices
2x USB 3.0/2.0 Devices, 2x SATA HDDs/SSDs Daisy Chain
Support Daisy Chain connections of up to six Thunderbolt devices
Note: the Daisy Chain will end if you connect a USB or Display device via USB-C TB3 Technology
Daisy Chain up to 6 devices
Bi-directional, dual-protocol (PCI Express and DisplayPort)
8 lanes of DisplayPort 1.2 supports dual 4K displays or one 5K display
Power delivery 15W to bus-powered devices
Backwards compatible with Thunderbolt 2 devices
USB-C ports are compatible with existing USB devices via USB-C cable, support up to USB 3.1 10Gb/s speed System Requirement
Computer with a USB-C (Thunderbolt 3)
Computer with a Thunderbolt 2 (via Thunderbolt 3 to Thunderbolt 2 Adapter)
macOS 10.10 and later
Windows 10 and later Enclosure Indicator
Power On (Blue) Chassis Design Features
Rugged, Ultra slim aluminum enclosure
Dual-Ultra Quiet, high-efficiency Cooling fans
Quick release thumbscrews for easy access Power Supply
External 60 watts power supply Material
Aluminum Power
Input AC 100-240V Output DC 12V 5A MTBF (Mean Time Before Failure)
920,585 Hours Certification / Approval
CE, FCC, RoHS, REACH, WEEE, Thunderbolt Kit Contents
2x USB 3.1 Gen 1 type A and 2x eSATA Ports Adapter
1x Thunderbolt 3 to PCIe Expansion Unit
1x 40Gb/s Thunderbolt 3 cable
1x External Power Supply
1x Power Cord
Quick Installation Guide Item Dimension (L"xW"xH")
3 x 7 x 11
Weight
6 lbs
Warranty Information
1 Year
