Technical Specifications
Processor / System Bus
1 x Socket LGA1150
Intel Xeon processor E3-1200 v3 product family
Generation
E8
Core Logic
Intel C224 Chipset Memory
Total Slots : 4 (2-channel)
Capacity : Maximum up to 32GB UDIMM
Memory Type :DDR3 1600/1333 UDIMM Expansion Slots
1 x PCI-E x16 (Gen3 x8 link) (Full-Height/HL)
1 x PCI-E x8 (Gen3 x4 link) (Full-Height/HL)
1x PIKE Slot for Stroage Enhancement Storage
SATA Controller :
Intel C224
2 x SATA2 3Gb/s ports
4 x SATA3 6Gb/s ports
Intel Rapid Storage Technology Enterprise(RSTe) (For Windows Only)
(Support Software RAID 0, 1, 5, 10 )
LSI MegaRAID (For Linux/Windows)
(Support Software RAID 0, 1, 10 ) HDD Bays
4 x Hot-swap 3.5" "HDD Bays
2 x SSD Bays(Optional)
Auxiliary Storage FDD/CD/DVD
Options: No Device Networking
4 x Intel I210AT + 1 x Mgmt LAN
Graphic
Aspeed AST2300 with 32MB VRAM
On Board I/O
1 x PS/2 KB/MS port
5 x RJ-45 ports (One for ASMB7-iKVM)
4 x USB 3.0 ports (Front x 2, Rear x 2)
2 x USB 2.0 ports (Front x 0, Rear x 2)
1 x Internal A Type USB Port
2 x VGA port (Front x 1, Rear x 1) OS Support
CentOS 5.8/6.3 64-bit
CentOS 5.8/6.2 64-bit
Windows Server 2012
Windows Server 2008 R2 Enterprise
Windows 8 32/64-bit
RedHat Enterprise Linux AS5.8/6.3 64-bit
x(Subject to change without any notice) Management Solution
Software: ASWM Enterprise
Out of Band Remote Management: Optional ASMB7-iKVM for KVM-over-IP
Regulatory Compliance
BSMI, CCC, CE, C-Tick, FCC(Class A) Form Factor
1U
Power Supply
1+1 Redundant 450W 80PLUS Gold Power Supply
Rating: 100-127Vac/200-240Vac,8A/4A ,47-63Hz, Class 1 Accessory Box
1 x RS300-E8 Users Guide
1 x ASUS ASWM Enterprise Users Guide
1 x Bag of Screws
2 x AC Power Cable
1 x ASUS Auto Installation DVD
1 x RS300-E8 Support DVD
1 x ASWM ENTERPRISE DVD Item Dimension (L"xW"xH"):
30 x 23 x 8
Weight:
35 lb
Warranty Information:
NA
