Intel R2224WFTZSR SY R2224WFTZSR Server System NO CPU 0.00GHZ Single Retail

Essentials
Product Collection
Intel Server System R2000WF Family
Code Name
Intel Server System R2224WFTZSR
Expected Discontinuance
2022
Chassis Form Factor
2U, Spread Core Rack
Board Form Factor
Custom 16.7" x 17"
Compatible Product Series
2nd Generation Intel Xeon Scalable Processors
Socket
Socket P
TDP
165 W
Heat Sink
(2) FXXCA78X108HS
Heat Sink Included
Yes
System Board
Intel Server Board S2600WFTR
Board Chipset
Intel C624 Chipset
Target Market
Mainstream
Rack-Friendly Board
Yes
Power Supply
1300 W
Power Supply Type
AC
Number of Power Supply Included
1
Redundant Power Supported
Supported, requires additional power supply
Backplanes
Included
Included Items
(1) 2U Chassis with Quick Reference Label affixed to top cover
(1) Intel Server Board S2600WFT (dual 10 GbE LAN)
(2) PCIe riser card brackets.
(2) 3-slot PCIe riser cards
(1) 2-slot low profile PCIe riser card
(24) 2.5" hot-swap drive bays with drive carriers and blanks.
(3) SAS/NVMe combo backplane
(24) 2.5" hot-swap drive tool less carriers
(1) Storage rack handle assembly - Mini front panel (board only)
(1) Backplane I2C cable
(2) Backplane to backplane I2C jumper cable
(2) Mini SAS HD VT-VT cable
(4) Mini SAS HD VT-VT cable
(1) Backplane power cable
(1) Standard 2U air duct
(6) Hot-swap system fans FR2UFAN60HSW
(16) DIMM slot blanks
(1) 1300W AC power supply module
(1) Power supply bay blank insert
(2) CPU heat sinks
(2) CPU heat sink "NO CPU" Mylar spacer insert
(2) Standard CPU carrier
(1) 3x Intel RAID Mai
Supplemental Information
Description
Integrated 2U system featuring an Intel Server Board S2600WFTR, supporting two 2nd Generation Intel Xeon Scalable processors, (24) 2.5 inch hot-swap drives, 24 DIMMs, (1)1100W redundant-capable power supply.
Memory and Storage
Memory Types
DDR4 ECC RDIMM/LRDIMM 2133/2400/2666/2933 and Intel Optane^o DC Persistent Memory Supported
Max number of DIMMs
24
Max Memory Size (dependent on memory type)
7.5 TB
Number of Front Drives Supported
24
Front Drive Form Factor
Hot-swap 2.5"
Number of Rear Drives Supported
2
Rear Drive Form Factor
2.5" SATA (optional)
Number of Internal Drives Supported
2
Internal Drive Form Factor
M.2 SSD
Intel Optane DC Persistent Memory Supported
Yes
Processor Graphics
Integrated Graphics
Yes
Expansion Options
PCIe x4 Gen 3
1
PCIe x8 Gen 3
3
PCIe x16 Gen 3
2
PCIe OCuLink Connectors (NVMe support)
4
Connector for Intel Integrated RAID Module
1
Riser Slot 1: Total number of Lanes
24
Riser Slot 2: Total number of Lanes
24
Riser Slot 3: Total number of Lanes
12
I/O Specifications
Number of USB Ports
5
Total of SATA Ports
10
RAID Configuration
SW RAID 0, 1, 10, optional 5
Number of Serial Ports
2
Integrated LAN
1GbE (mgmt port) + Dual Port RJ45 10GbE
Number of LAN Ports
3
Optical Drive Support
Yes
Package Specifications
Max CPU Configuration
2
Advanced Technologies
Intel Optane^TMMemory Supported
Yes
Intel Remote Management Module Support
Yes
Integrated BMC with IPMI
IPMI 2.0
Intel Node Manager
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Rapid Storage Technology enterprise
Yes
TPM Version
2.0
Item Dimension (L"xW"xH")
39 x 23 x 10
Weight
65.00 LB
Warranty Information
3 Year Standard
