R2208WFTZSR - Intel SY R2208WFTZSR Server System NO CPU 0.00GHZ Single Retail

Special Order
Ships in 1-2 weeks
Condition: New

$2,097.66  $2,831.84
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

General InformationCustomers want data center products designed for outstanding performance and reliability that will address their unique needs. With Intel Server Systems and Intel Server Chassis, you can count on trusted performance, quality, and reliability to help solve the most complex business challenges.Processor & ChipsetNumber of Processors Supported: 2Processor Supported: Xeon PlatinumProcessor Supported: Xeon GoldProcessor Supported: Xeon SilverProcessor Supported: Xeon Bronze64-bit Processing: YesChipset Manufacturer: IntelChipset Model: C624MemoryMaximum Memory: 7.50 TBMemory Technology: DDR4 SDRAMMemory Standard: DDR4-2933/PC4-23466Number of Total Memory Slots: 24Intel Optane Memory Ready: YesControllersController Type: 12Gb/s SASRAID Supported: YesNetwork & CommunicationEthernet Technology: Gigabit EthernetI/O ExpansionsNumber of Total Expansion Bays: 9Number of External 5.25" Bays: 1Number of Internal 2.5" Bays: 8Interfaces/PortsTotal Number of USB Ports: 5Number of SATA Interfaces: 10Power DescriptionNumber of Power Supplies Installed: 1Maximum Power Supply Wattage: 1300 WPhysical CharacteristicsForm Factor: Rack-mountableRack Height: 2UHeight: 3.4"Width: 16.9"Depth: 28"MiscellaneousPackage Contents: Server System R2208WFTZSR 1 x 2U Chassis with Quick Reference Label affixed to top cover 1 x Intel Server Board S2600WFTR (dual 10 GbE LAN) 2 x PCIe riser card brackets. 2 x 3-slot PCIe* riser cards 1 x 2-slot low profile PCIe* riser card A2UX8X4RISER 8 x 2.5" hot-swap drive bays with drive carriers and blanks. 1 x SAS/NVMe combo 8 x 2.5" hot-swap drive tool less carriers 1 x Standard control panel assembly (board only) 1 x - Front I/O panel assembly (1 x VGA and 2 x USB) 1 x Backplane I2C cable 2 x Mini SAS HD cable 1 x 400/525/675 mm backplane power cable 1 x SATA optical drive power cable 1 x SATA optical drive bay mounting kit 1 x Standard 2U air duct 6 x Hot-swap system fans FR2UFAN60HSW 8 x DIMM slot blanks 1 x 1300W AC power supply module 1 x Power supply bay blank insert 2 x AC Power cord retention strap assembly 2 x CPU heat sinks WarrantyLimited Warranty: 3 Year

Technical Specifications

Essentials
Product Collection
Intel Server System R2000WF Family
Code Name
Intel Server System R2208WFTZSR
Expected Discontinuance
2022
Chassis Form Factor
2U, Spread Core Rack
Board Form Factor
Custom 16.7" x 17"
Compatible Product Series
2nd Generation Intel Xeon Scalable Processors
Socket
Socket P
TDP
205 W
Heat Sink
(2) FXXCA78X108HS
Heat Sink Included
Yes
System Board
Intel Server Board S2600WFTR
Board Chipset
Intel C624 Chipset
Target Market
Mainstream
Rack-Friendly Board
Yes
Power Supply
1300 W
Power Supply Type
AC
of Power Supply Included
1
Redundant Power Supported
Supported, requires additional power supply
Backplanes
Included
Included Items
(1) 2U Chassis with Quick Reference Label affixed to top cover
(1) Intel Server Board S2600WFTR (dual 10 GbE LAN)
(2) PCIe riser card brackets.
(2) 3-slot PCIe riser cards
(1) 2-slot low profile PCIe riser card A2UX8X4RISER
(8) 2.5" hot-swap drive bays with drive carriers and blanks.
(1) SAS/NVMe combo
(8) 2.5" hot-swap drive tool less carriers
(1) Standard control panel assembly (board only)
(1) -Front I/O panel assembly (1 x VGA and 2 x USB)
(1) Backplane I2C cable
(2) Mini SAS HD cable
(1) 400/525/675 mm backplane power cable
(1) SATA optical drive power cable
(1) SATA optical drive bay mounting kit
(1) Standard 2U air duct
(6) Hot-swap system fans FR2UFAN60HSW
(8) DIMM slot blanks
(1) 1300W AC power supply module
(1) Power supply bay blank insert
(2) AC Power cord retention strap assembly
(2) CPU heat sinks
(2) CPU heat s
Supplemental Information
Description
Integrated 2U system featuring an Intel Server Board S2600WFTR, supporting two 2nd Generation Intel Xeon Scalable processors, (8) 2.5 inch hot-swap drives, 24 DIMMs, (1)1100W redundant-capable power supply.
Memory and Storage
Memory Types
DDR4 ECC RDIMM/LRDIMM 2133/2400/2666/2933 and Intel OptaneTM DC Persistent Memory Supported
Max number of DIMMs2
4
Max Memory Size (dependent on memory type)
7.5 TB
Number of Front Drives Supported
8
Front Drive Form Factor
Hot-swap 2.5"
Number of Rear Drives Supported
2
Rear Drive Form Factor
2.5" SATA (optional)
Number of Internal Drives Supported
2
Internal Drive Form Factor
M.2 SSD
Intel OptaneTM DC Persistent Memory Supported
Yes
Processor Graphics
Integrated Graphics
Yes
Expansion Options
PCIe x4 Gen 3
1
PCIe x8 Gen 3
3
PCIe x16 Gen 3
2
PCIe OCuLink Connectors (NVMe support)
4
Connector for Intel Integrated RAID Module
1
Riser Slot 1: Total number of Lanes
24
Riser Slot 2: Total number of Lanes
24
Riser Slot 3: Total number of Lanes
12
I/O Specifications
Number of USB Ports
5
Total number of SATA Ports
10
RAID Configuration
SW RAID 0, 1, 10, optional 5
Number of Serial Ports
2
Integrated LAN
1GbE (mgmt port) + Dual Port RJ45 10GbE
Number of LAN Ports
3
Optical Drive Support
Yes
Package Specifications
Max CPU Configuration
2
Advanced Technologies
Intel OptaneTMMemory Supported
Yes
Intel Remote Management Module Support
Yes
Integrated BMC with IPMI
IPMI 2.0
Intel Node Manager
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Rapid Storage Technology enterprise
Yes
TPM Version
2.0
Item Dimension (L"xW"xH")
39 x 23 x 10
Weight
65.00 LB
Warranty Information
3 Year Standard

Product Details

  • Manufacturer:
  • Model Number:
  • ASIN:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Intel
  • R2208WFTZSR
  • B07QZHJBJL
  • 735858406840
  • New
  • 40.67 lbs
  • 0 X 0 X 0
  • May 15, 2026
  • Apr 12, 2019
Product Identifiers: Brand: Intel • Part #: R2208WFTZSR • UPC: 735858406840 • ASIN: B07QZHJBJL • Category: Computer Servers
