General InformationCustomers want data center products designed for outstanding performance and reliability that will address their unique needs. With Intel Server Systems and Intel Server Chassis, you can count on trusted performance, quality, and reliability to help solve the most complex business challenges.Processor & ChipsetNumber of Processors Supported: 2Processor Supported: Xeon PlatinumProcessor Supported: Xeon GoldProcessor Supported: Xeon SilverProcessor Supported: Xeon Bronze64-bit Processing: YesChipset Manufacturer: IntelChipset Model: C624MemoryMaximum Memory: 7.50 TBMemory Technology: DDR4 SDRAMMemory Standard: DDR4-2933/PC4-23466Number of Total Memory Slots: 24Intel Optane Memory Ready: YesControllersController Type: Serial ATARAID Supported: YesNetwork & CommunicationEthernet Technology: 10 Gigabit EthernetI/O ExpansionsNumber of Total Expansion Bays: 8Number of Internal 2.5" Bays: 8Interfaces/PortsTotal Number of USB Ports: 5Number of SATA Interfaces: 10Power DescriptionNumber of Power Supplies Installed: 1Maximum Power Supply Wattage: 1100 WPhysical CharacteristicsForm Factor: Rack-mountableRack Height: 1UHeight: 1.7"Width: 16.9"Depth: 28"MiscellaneousPackage Contents: Server System R1208WFTYSR 1 x Intel Server Board S2600WFTR (dual 10GbE LAN) 1 x 1U chassis with Quick Reference Label affixed to top cover 1 x SAS/NVMe Combo backplane F1U8X25S3PHS 8 x 2.5" hot swap drive tool less carriers FXX35HSCAR3 1 x Pre-installed standard control panel assembly FXXFPANEL2 1 x Pre-installed front I/O panel assembly (1x VGA and 2x USB) 1 x 200mm backplane I2C cable 1 x 650mm mini SAS HD Cable AXXCBL650HDHRT 1 x 850mm mini SAS HD cable AXXCBL850HDHRT 1 x 400mm backplane power cable 1 x Air duct 6 x Dual rotor system fans FR1UFAN10PW 2 x CPU heat sinks FXXCA78X108HS 2 x CPU heat sink "No CPU" label inserts 2 x Standard CPU carriers 2 x 1 slot PCIe x16 Riser Card 1 x Chassis Stiffener Bar 1 x Power supply bay blank insert WarrantyLimited Warranty: 3 Year
Technical Specifications
Essentials Product Collection Intel Server System R1000WF Family Code Name Products formerly Wolf Pass Extended Warranty Available for Purchase (Select Countries) Yes Additional Extended Warranty Details Dual Processor Board Extended Warranty Chassis Form Factor 1U, Spread Core Rack Board Form Factor Custom 16.7" x 17" Compatible Product Series 2nd Generation Intel Xeon Scalable Processors Socket Socket P TDP 165 W Heat Sink (2) 1U Standard Heat Sink FXXCA78X108HS Heat Sink Included Yes System Board Intel Server Board S2600WFTR Board Chipset Intel C624 Chipset Target Market Mainstream Rack-Friendly Board Yes Power Supply 1100 W Power Supply Type AC Number of Power Supply Included 1 Redundant Power Supported Supported, requires additional power supply
