R1208WFQYSR - Intel Server System R1208WFQYSR FD

Essentials
Product Collection
Intel Server System R1000WF Family
Code Name
Products formerly Wolf Pass
Extended Warranty Available for Purchase (Select Countries)
Yes
Additional Extended Warranty Details
Dual Processor Board Extended Warranty
Chassis Form Factor
1U, Spread Core Rack
Board Form Factor
Custom 16.7" x 17"
Compatible Product Series
2nd Generation Intel Xeon Scalable Processors
Socket
Socket P
TDP
165 W
Heat Sink
(2) 1U Standard Heat Sink FXXCA78X108HS
Heat Sink Included
Yes
System Board
Intel Server Board S2600WFQR
Board Chipset
Intel C628 Chipset
Target Market
Mainstream
Rack-Friendly Board
Yes
Power Supply
1100 W
Power Supply Type
AC
Number of Power Supply Included
1
Redundant Power Supported
Supported, requires additional power supply
Backplanes
Included Included Items
(1) 1U chassis with Quick Reference Label affixed to top cover
(1) Intel Server Board S2600WFQR (Intel QAT support)
(2) Riser card assembly with 1 slot PCIe x16 riser card F1UL16RISER3
(8) 2.5 hot-swap drive bays with drive carriers and drive blanks. Includes:
(1) SAS/NVMe Combo backplane F1U8X25S3PHS
(8) 2.5 hot swap drive tool less carriers FXX35HSCAR3
(1) Pre-installed standard control panel assembly (board only FXXFPANEL2)
(1) Pre-installed front I/O panel assembly (1x VGA and 2x USB)
(1) 200mm backplane I2C cable
(1) 650mm mini SAS HD Cable AXXCBL650HDHRT
(1) 850mm mini SAS HD cable AXXCBL850HDHRT
(1) 400mm backplane power cable
(1) 290 mm Intel QAT cable
(1) Air duct
(6) Dual rotor system fans FR1UFAN10PW
(1) 1100W power supply module AXX1100PCRPS
(2) CPU heat sinks, 39 fin passive
(2) CPU heat sink No CPU label inserts
(2) Standard CPU carriers Supplemental Information
Description
Integrated 1U system featuring an Intel Server Board S2600WFQR, supporting two 2nd Generation Intel Xeon Scalable processors, (8) 2.5 inch hot-swap drives, 24 DIMMs, (1)1100W redundant-capable power supply, Intel OCP Module. Memory and Storage
Memory Types
DDR4 ECC RDIMM/LRDIMM 2133/2400/2666/2933 Intel Optane DC Persistent Memory Supported
Max Number of DIMMs
24
Max Memory Size (dependent on memory type)
7.5 TB
Number of Front Drives Supported
8
Front Drive Form Factor
Hot-swap 2.5"
Number of Internal Drives Supported
2
Internal Drive Form Factor
M.2 SSD
Intel Optane DC Persistent Memory Supported
Yes Processor Graphics
Integrated Graphics
Yes Expansion Options
PCIe x24 Riser Super slot
1
PCIe x16 Gen 3
2
PCIe OCuLink Connectors (NVMe support)
2
Connector for Intel Integrated RAID Module
1
Riser Slot 1: Total Number of Lanes
24
Riser Slot 1: Included Slot Configuration(s)
1x PCIe Gen3 x16
Riser Slot 2: Total Number of Lanes
24
Riser Slot 2: Included Slot Configuration(s)
1x PCIe Gen3 x16 I/O Specifications
Number of USB Ports
5
Total Number of SATA Ports
2
Number of UPI Links
3
RAID Configuration
SW RAID 0/1
Number of Serial Ports
2
Integrated LAN
1GbE (mgmt port)
Number of LAN Ports
1 Package Specifications
Max CPU Configuration
2 Advanced Technologies
Intel Optane Memory Supported
No
Intel Remote Management Module Support
Yes
Integrated BMC with IPMI
IPMI 2.0 and Redfish
Intel Node Manager
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Rapid Storage Technology enterprise
Yes
TPM Version
2.0 Intel Transparent Supply Chain
Includes Statement of Conformance and Platform Certificate
Yes Item Dimension (L"xW"xH")
39 x 23 x 10

Weight
65 lbs

Warranty Information
3 Year Standard
