General InformationThe QNAP QNA series is a cost-effective Thunderbolt 3 to 10GbE adapter that empowers your Mac or Windows computers with blazing-fast 10GbE network connectivity using a Thunderbolt 3 type-C port. With the portable QNA series adapter, a 10GbE network can be created between your Thunderbolt 3 computer and another 10GbE-capable device or NAS to facilitate high-speed data transfer for large files and help to streamline collaborative workflows to improve efficiency. Enable blazing-fast 10GbE connectivity for your Mac With the QNA series adapters, you can connect your Mac and Windows computers to a 10GbE network to enjoy access speeds of up to 1069 MB/s. With both Thunderbolt 3 and 10GbE connectivity, your data transfers will be faster than ever! 10GbE data transfer that media professionals need As video resolutions move from 1080p, to 4K, 8K (and beyond) media creators are struggling with the storage and network requirements needed for editing huge multimedia files. The QNA series comes with two models. The QNA-T310G1T features a Thunderbolt 3 to 10GbE Multi-Gigabit (10G/5G/2.5G/1G/100M) port, and the QNA-T310G1S features one 10GbE SFP+ port, allowing you to easily add 10GbE connectivity to any Thunderbolt 3 device. Coupled with a QNAP 10GbE switch, a budget-friendly 10GbE environment can be created for creative studios to benefit from the incredible speed and bandwidth that 10GbE provides. StylishThe QNA series features a metallic bright-toned cover that fits perfectly alongside other devices.PortableThe QNA series requires no extra power supply, and you can easily carry it around for universal deployment.Heat DissipationThe QNA series has shallow grooves on its top for effective heat dissipation. Effortless setup Simply connect a QNA adapter to your Mac or Windows computer using the included Thunderbolt 3 cable and connect the adapter to a 10GbE-capable switch, NAS, or other device using a 10GbE cable (RJ45 Cat 5e/Cat 6a cable or above or a SFP+ DAC). Interfaces/PortsHost Interface: Thunderbolt 3Total Number of Ports: 1Number of Network (RJ-45) Ports: 1Media & PerformanceMedia Type Supported: Twisted PairNetwork & CommunicationNetwork Technology: 10GBase-TPhysical CharacteristicsForm Factor: PortableHeight: 1.1"Width: 2.2"Depth: 4.4"MiscellaneousDevice Supported: Computer/Notebook
Technical Specifications
Interface Single-port Thunderbolt 3 to single-port 10GbE NBASE-T RJ-45 Data Transfer 10Gbps 5Gbps 2.5Gbps 1Gbps 100Mbps Cables Thunderbolt 3: Thunderbolt 3 cable Network Cable: CAT 5e, CAT 6, CAT 6A, CAT 7 0.5M Thunderbolt3 40Gb/s cable x 1 included Suggest using CAT 6 (or above) cable to achieve 10GbE transfer speed Power Supply Unit Bus powered System Requirements (Windows) Windows 7 (64-bit) / Windows 10 (64-bit) Required download Aquantia AQC107 driver Required a Thunderbolt 3 port on your computer System Requirements (Mac) macOS 10.13.3 (or later) Required a Thunderbolt 3 port on your computer System Requirements (QNAP NAS) QNAP Thunderbolt 3 NAS (will be supported in Q4/2018) Operating Temperature and Relative Humidity 100M CAT 6A: 35o 50M CAT 6A: 40o 5-95% (non-condensing) LED Indicators Power, LAN Link/Act, transfer speed Package Contents QNA-T310G1T, 0.5M Thunderbolt 3 cable x 1, installation guide Item Dimension (L"xW"xH") 6 x 5 x 21
Weight 5 lbs
Warranty Information 2 Years
Product Details
Manufacturer:
Model Number:
ASIN:
UPC:
Condition:
Weight:
Dimensions:
Updated:
Added:
Country of Origin:
QNAP
QNA-T310G1T
B07KTLGTXB
885022016686
New
0.42 lbs
4 X 1 X 2
Jun 13, 2026
May 10, 2019
TW
Product Identifiers:
Brand: Qnap •
Part #: QNA-T310G1T • UPC: 885022016686 • ASIN: B07KTLGTXB • Category: Disk Array Components
