Technical Specifications
<b> P/N</b><br>PS-TPD-1200MPCG <br><br><b> Short P/N</b><br>TPD-1200M<br><b> Model</b><br>TP-1200AH5CEG <br><br><b> Type</b><br>Intel ATX 12V V2.3 and EPS 12V standards <b> Max. Output Capacity</b><br>1200W <br><br><b> Peak Output Capacity</b><br>1250W <br><br><b> Color</b><br>Black <br><br><b> Dimension (H x W x D) </b><br>86mm x 150mm x 180mm <b> PFC Power Factor Correction</b><br>Active PFC <br><br><b> Power Good Signal</b><br>100-500 msec <br><br><b> Hold Up Time</b><br>16msec (minimum) at 75% of full load at 115V / 230V input. <b> Input current</b><br>12A - 6A <br><br><b> Input Frequency Range</b><br>60 Hz - 50 Hz <br><br><b> Input Voltage</b><br>115 Vac- 240 Vac <br><br><b> Operating Temperature</b><br>0 to +40 <br><br><b> Operating Humidity</b><br>10% to 90%,non-condensing <b> Storage Temperature</b><br>-20 to +60 <br><br><b> Storage Humidity</b><br>5% to 95%, non-condensing <br><br><b> Cooling System</b><br>135mm double ball-bearing fan, 150010%R.P.M. <br><br><b> Efficiency</b><br>87-92% efficiency at 20-100% load <b> MTBF</b><br>120,000 hrs minimum <br><br><b> Safety Approval</b><br>UL/ CB+Baurt mark/ CE/ FCC/ CCC/ GOST certification <br><br><b> PCI-E Connector</b><br>PCI-E 6+2pin x 8 <b> Item Dimension (L"xW"xH"):</b><br> 13.78 x 8.46 x 6.69<br><br><b>Weight:</b><br>8.91 lb<br><br><b>Warranty Information:</b><br> 5 years
