Technical Specifications
OVERVIEW
PDU Type:Switched
OUTPUT
Output Capacity Details:3.84kW (240V), 3.68kW (230V), 3.52kW (220V), 3.33kW (208V), 3.2kW (200V) / 16A total capacity 16A max per C19 outlet 12A (10A CE) max per C13 outlet
Frequency Compatibility:50 / 60 Hz
Output Receptacles:(20) C13 (4) C19
Output Nominal Voltage:200 208 220 230 240
Overload Protection:n/a
Customized Load Management Receptacles:Each outlet is individually controllable via remote interface
INPUT
PDU Input Voltage:200 208 220 230 240
Recommended Electrical Service:20A 208/240V 16A 230V
Maximum Input Amps:20
Maximum Input Amps Details:Agency de-rated to 16A continuous
Input Connection Type:C20 inlet accepts included L6-20P input cable
PDU Plug Type:NEMA L6-20P IEC-320 C20
Input Cord Length (m):3.05
Input Phase:Single-Phase
USER INTERFACE, ALERTS and CONTROLS
Front Panel LCD Display:Digital meter reports PDU output current in amps
Front Panel LEDs:24 power availability LEDs confirm power off/on status for each built-in outlet
PHYSICAL
Form Factors Supported:0U vertical rackmount includes rackmount brackets. Supports toolless mounting in button-mount compatible racks
PDU Form Factor:0U Vertical
ENVIRONMENTAL
Storage Temperature Range:5 to 140F (-15 to 60C)
Relative Humidity:Up to 95% non-condensing
Operating Elevation (ft.):Up to 10,000
Operating Elevation (m):Up to 3000
COMMUNICATIONS
SNMP Compatibility:Built-in LX Platform Interface
CERTIFICATIONS
Certifications:Tested to UL 60950-1:2007 (USA), CAN/CSA-C22.2 NO. 60950-1-07 (Canada), IEC 60950-1: 2005 (CE), FCC Class A, EN55022:2010+2011, EN55024:2010 (Emissions), NOM (Mexico), RoHS compliant, TAA Compliant
Item Dimension (L inchxW inchxH inch)
73 x 7 x 6 Weight
19.00lb Warranty Information
2-year limited warranty
